Arista SFP-10G-SRL – 10GBASE-SRL SFP+ Optical Transceiver
The Arista SFP-10G-SRL from Datacom Technologies BD is a high-performance 10 Gigabit optical transceiver designed for extended short-reach connectivity over multimode fiber. It is ideal for enterprise networks and data centers that require longer MMF reach than standard SR optics while maintaining reliable, low-latency 10G transmission on Arista SFP+-enabled platforms.
Specification Table
| Feature | Details |
|---|
| Product Name | Arista SFP-10G-SRL |
| Form Factor | SFP+ |
| Data Rate / Capacity | 10Gbps |
| Standard / Protocol | 10GBASE-SRL |
| Fiber Type / Interface | Multimode Fiber (MMF) |
| Wavelength / Technology | 850 nm |
| Transmission Distance | Up to 400 m (OM4) / 300 m (OM3) |
| Connector Type | Duplex LC |
| Lane Configuration | 1 × 10G |
| Modulation | NRZ |
| Compliance | IEEE 802.3ae, RoHS |
| Compatibility | Arista SFP+ switches and network adapters |
| Application | Extended short-reach data center and enterprise networking |
Arista SFP-10G-SRL Description
The Arista SFP-10G-SRL optical transceiver is engineered to deliver dependable 10G Ethernet connectivity over multimode fiber with extended reach beyond standard SR optics. Operating at an 850 nm wavelength, it supports longer transmission distances, making it suitable for larger data halls and aggregation layers within enterprise and data center environments.
Its compact and hot-pluggable SFP+ form factor enables high port density while maintaining low power consumption and thermal stability. Fully tested for interoperability with Arista networking equipment, the SRL transceiver provides a scalable, cost-effective, and reliable solution for extending 10G connectivity where longer MMF links are required.
Key Features
• Supports 10Gbps high-speed optical transmission
• SRL extended short-reach multimode fiber connectivity
• Up to 400 m reach on OM4 fiber
• 850 nm wavelength for stable performance
• Duplex LC connector for easy deployment
• Low power consumption and high reliability
• Hot-pluggable SFP+ form factor
• Optimized for Arista switching platforms
Where It Can Be Used
• Enterprise and hyperscale data centers
• Aggregation and distribution layers
• Large data halls with extended MMF links
• Cloud computing and virtualization platforms
• High-performance computing (HPC) environments
• High-density 10G switching deployments
