| Specification | Details |
|---|
| Model | Cisco C9200‑48T‑A |
| Product Type | Managed Layer 2/Layer 3 Access Switch |
| Series | Cisco Catalyst 9200 |
| Software Edition | Cisco IOS XE Network Advantage |
| Downlink Ports | 48 × 10/100/1000 Mbps RJ‑45 |
| Uplink Module Slot | 1 × modular uplink slot (supports optional uplink modules) |
| Switching Capacity | 176 Gbps |
| Forwarding Rate | ~130.95 Mpps (64‑byte packets) |
| Stacking | StackWise‑160, up to 8 switches, 160 Gbps stacking bandwidth |
| MAC Address Table | 32,000 entries |
| VLAN Support | Up to 4096 VLANs |
| SVIs Supported | Up to 512 |
| Jumbo Frames | Up to 9,216 bytes |
| Memory | 4 GB DRAM, 4 GB Flash |
| Power Supply | 1 × 250W AC (field‑replaceable) |
| Fans | Redundant, field‑replaceable |
| Dimensions (H×W×D) | Approx. 1.73″ × 17.5″ × 13.8″ |
| Weight | ~6.0 kg |
| Layer 3 Routing | Static routing, RIP, OSPF, EIGRP Stub |
| Security Features | 802.1X, MACsec, ACLs, Control Plane Protection |
| Monitoring & Telemetry | NetFlow, SPAN, EEM, RESTCONF/NETCONF |
Product Description:
The Cisco C9200‑48T‑A Catalyst 9200 Series Switch is a robust, enterprise‑class access‑layer switch designed to support modern business networks with high port density, advanced features, and scalable performance. With 48 Gigabit Ethernet RJ‑45 ports, it delivers ample connectivity for desktops, servers, and IP devices, while a modular uplink slot allows flexible expansion using optional uplink modules for higher‑speed connectivity to distribution or core layers.
Running on Cisco IOS XE Network Advantage software, the C9200‑48T‑A offers comprehensive Layer 2 switching along with full Layer 3 routing capabilities, including OSPF and EIGRP stub support, giving network administrators powerful tools for segmentation, traffic management, and dynamic routing. The switch supports StackWise‑160 stacking, enabling up to eight switches to operate as a single logical unit with 160 Gbps of stacking bandwidth, streamlining management and delivering high‑availability network operation.
Security is built in with support for 802.1X authentication, MACsec encryption, access control lists (ACLs), and control plane protection, helping safeguard network access and traffic flows. With support for up to 4096 VLANs, a 32,000‑entry MAC address table, and advanced telemetry and monitoring features such as NetFlow, SPAN, and RESTCONF/NETCONF, this model is ideal for enterprise campuses, branch offices, and distributed networks needing high performance, resiliency, and simplified operations.
