About Broadcom 05-25699-00 SAS9305-24I 24-Port 12Gb/s SAS PCIe HBA Card in Bangladesh
The Broadcom 05-25699-00 SAS9305-24I 24-Port 12Gb/s SAS PCIe HBA Card is a high-density enterprise Host Bus Adapter designed for storage servers, enterprise NAS, virtualization platforms, software-defined storage, and hyperscale data centers. Powered by the Broadcom SAS3224 Fusion-MPT 2.5 controller, it delivers exceptional performance, low latency, and enterprise-class reliability for mission-critical storage environments.
Featuring a PCI Express 3.0 x8 interface and six internal Mini-SAS HD (SFF-8643) connectors, the adapter provides twenty-four internal 12Gb/s SAS/SATA lanes for connecting large numbers of SAS HDDs, SAS SSDs, SATA HDDs, and SATA SSDs. Its high-density design maximizes storage expansion while minimizing PCIe slot usage.
The SAS9305-24I operates in IT (Initiator Target) mode, making it ideal for TrueNAS, ZFS, VMware ESXi, Microsoft Storage Spaces, Linux storage servers, Proxmox VE, Ceph, Unraid, backup servers, and enterprise cloud storage. Enterprise technologies include Fusion-MPT 2.5 architecture, SGPIO, SES, SSD TRIM, S.M.A.R.T., Native Command Queuing (NCQ), Hot Plug support, and SAS expanders supporting up to 1024 SAS/SATA devices.
Whether building enterprise NAS appliances, virtualization clusters, cloud infrastructure, backup systems, or large-scale storage servers, the Broadcom 05-25699-00 SAS9305-24I delivers outstanding scalability, high throughput, and dependable enterprise performance.
Buy Broadcom 05-25699-00 SAS9305-24I 24-Port 12Gb/s SAS PCIe HBA Card in Bangladesh
Looking for the original Broadcom 05-25699-00 SAS9305-24I 24-Port 12Gb/s SAS PCIe HBA Card in Bangladesh? Datacom Technologies (BD) supplies genuine Broadcom enterprise storage adapters with competitive prices, professional consultation, and reliable after-sales support.
Compatibility
- Enterprise Rack Servers
- PCI Express 3.0 x8 Systems
- 12Gb SAS HDD & SSD
- 6Gb SATA HDD & SSD
- TrueNAS CORE & SCALE
- VMware ESXi
- Microsoft Windows Server
- Linux (Ubuntu, Debian, RHEL, SUSE)
- Proxmox VE
- Ceph & Unraid
Broadcom 05-25699-00 SAS9305-24I Specifications & Overview
| Specification |
Details |
| Product Type | SAS/SATA Host Bus Adapter |
| Product Name | Broadcom 05-25699-00 SAS9305-24I 24-Port 12Gb/s SAS PCIe HBA Card |
| Brand | Broadcom |
| Model | SAS9305-24I |
| Manufacturer Part Number | 05-25699-00 |
| Controller | Broadcom SAS3224 Fusion-MPT 2.5 |
| Host Interface | PCI Express 3.0 x8 |
| Internal Ports | 24 × 12Gb/s SAS/SATA |
| Internal Connectors | 6 × Mini-SAS HD (SFF-8643) |
| Supported Drives | SAS HDD, SAS SSD, SATA HDD, SATA SSD |
| Transfer Rate | 12Gb/s SAS / 6Gb/s SATA |
| Operating Mode | IT (Non-RAID) HBA |
| Maximum Device Support | Up to 1024 SAS/SATA Devices |
| Performance | More than 1.5 Million IOPS |
| Supported Features | Fusion-MPT 2.5, SGPIO, SES, SSD TRIM, S.M.A.R.T., NCQ, Hot Plug |
| Form Factor | Low Profile PCIe Card (Full-height Bracket Included) |
Applications
- Enterprise Storage Servers
- Enterprise NAS
- TrueNAS & ZFS Storage
- Virtualization Platforms
- Software-Defined Storage
- Database Servers
- Backup Infrastructure
- Cloud Storage
- JBOD Storage Expansion
- Hyperscale Data Centers
Benefits of Choosing This Product
The Broadcom SAS9305-24I provides enterprise-grade 24-port SAS connectivity, excellent scalability, low latency, high IOPS, and reliable storage performance for mission-critical enterprise applications.
Why Buy from Datacom Technologies (BD)?
Datacom Technologies (BD) is a trusted supplier of enterprise servers, storage systems, networking equipment, and data center hardware in Bangladesh. We provide genuine Broadcom storage products with competitive pricing, expert consultation, and dependable after-sales support.
- Call/WhatsApp: +8801748173213
- Email: sales@datacom.com.bd
- Alternative Email: datacomtechnologiesbd@gmail.com
- Office: Tropical Center, 218, Dr. Kudroti Khuda Road, New Elephant Road, Dhaka-1205, Bangladesh.
Frequently Asked Questions (FAQ)
Q1: Is 05-25699-00 the official part number for the SAS9305-24I?
Yes. 05-25699-00 is the official Broadcom manufacturer part number for the SAS9305-24I.
Q2: Does it support hardware RAID?
No. It is an IT-mode Host Bus Adapter designed for direct disk connectivity.
Q3: How many internal connectors are available?
It includes six Mini-SAS HD (SFF-8643) connectors supporting 24 internal SAS/SATA lanes.
Q4: Which operating systems are supported?
It supports VMware ESXi, Windows Server, Linux, TrueNAS, Proxmox VE, Ceph, and Unraid.
Q5: How many storage devices can it support?
It supports up to 1024 SAS/SATA devices using compatible SAS expanders.
