About Brocade 57-1000352-01 100GBASE-ESR4 QSFP28 850nm 300m Transceiver Module in Bangladesh
The Brocade 57-1000352-01 is a 100GbE QSFP28 optical transceiver designed for high-speed short-range data-center and enterprise network connectivity. It uses the 100GBASE-ESR4 optical standard and operates over multimode fiber with a reach of up to 300 meters.
Brocade documentation identifies part number 57-1000352-01 as the 100G-QSFP-ESR4 optic. The documented configuration uses an MTP 1x8 or 1x12 optical interface and supports distances up to 300m over multimode fiber. :contentReference[oaicite:1]{index=1}
Brocade 57-1000352-01 100G QSFP28 Transceiver Specifications & Features
| Specification | Details |
|---|
| Brand | Brocade |
| Part Number | 57-1000352-01 |
| Product Identifier | 100G-QSFP-ESR4 |
| Data Rate | 100Gb/s |
| Form Factor | QSFP28 |
| Optical Standard | 100GBASE-ESR4 |
| Wavelength | 850nm |
| Maximum Reach | Up to 300m |
| Fiber Type | Multimode Fiber (MMF) |
| Connector | MTP/MPO |
| Application | 100GbE Data Center Networking |
Overview
The Brocade 57-1000352-01 is a high-speed 100GbE QSFP28 transceiver designed for short-distance optical networking. Its 100GBASE-ESR4 architecture is intended for high-bandwidth connections over multimode fiber in data-center and enterprise environments.
With support for links up to 300 meters over multimode fiber, the module is well suited for switch-to-switch, switch-to-server and other high-speed data-center interconnect applications.
Buy Brocade 57-1000352-01 100G QSFP28 Transceiver in Bangladesh
Purchase the Brocade 57-1000352-01 100GBASE-ESR4 QSFP28 850nm 300m Transceiver Module from Datacom Technologies (BD). We supply Brocade optical transceivers, QSFP/QSFP28 modules, Ethernet networking equipment, data-center connectivity products and enterprise network hardware in Bangladesh.
Key Features
- 100Gb/s high-speed optical connectivity
- QSFP28 form factor
- 100GBASE-ESR4 optical standard
- 850nm wavelength
- Up to 300m reach over multimode fiber
- MTP/MPO optical connector
- Designed for short-range data-center interconnects
- Suitable for compatible Brocade networking equipment
- Ideal for high-bandwidth enterprise networks
- Suitable for switch-to-switch and switch-to-server links
Applications
- 100GbE Data Center Networks
- Core and Aggregation Networking
- Switch-to-Switch Connectivity
- Switch-to-Server Connectivity
- Data Center Interconnects
- Enterprise Network Upgrades
- High-Bandwidth Server Connectivity
- Cloud Infrastructure
- Virtualized Data Centers
- High-Performance Computing Networks
100Gbps High-Speed Connectivity
The Brocade 57-1000352-01 provides 100Gb/s optical connectivity in a compact QSFP28 form factor. It is designed for high-bandwidth networking environments where faster interconnects are required between switches, servers and data-center infrastructure.
Deploying 100GbE optical links can help reduce network bottlenecks and provide greater aggregate bandwidth for demanding data-center applications.
100GBASE-ESR4 Optical Standard
The 57-1000352-01 is identified as a 100GBASE-ESR4 optical transceiver. Brocade documentation lists the part under the 100G-QSFP-ESR4 product identifier. :contentReference[oaicite:2]{index=2}
ESR4 is designed for short-range 100GbE connectivity over multimode optical fiber, making it appropriate for data-center environments where equipment is located within the supported optical reach.
850nm Multimode Optics
The transceiver uses short-wavelength multimode optical technology around the 850nm range. This optical architecture is intended for short-distance high-speed links using multimode fiber.
Multimode fiber is commonly used inside data centers because it provides a practical and cost-effective medium for short-range high-bandwidth connections.
Up to 300m Transmission Distance
The Brocade 57-1000352-01 supports transmission distances of up to 300 meters over multimode fiber according to Brocade/Extreme Networks documentation. :contentReference[oaicite:3]{index=3}
The actual achievable distance depends on the installed fiber type, optical infrastructure, link quality and the capabilities of the connected equipment.
MTP/MPO Connector
The 100GBASE-ESR4 module uses an MTP/MPO-style multifiber connector. Brocade documentation identifies the optic with an MTP 1x8 or 1x12 interface. :contentReference[oaicite:4]{index=4}
Before deployment, verify that the installed fiber patch cable, polarity and connector configuration match the transceiver and the connected networking equipment.
QSFP28 Form Factor
The Brocade 57-1000352-01 uses the compact QSFP28 form factor. QSFP28 optics are widely used for 100GbE networking and provide high port density in modern switches and data-center platforms.
The compact design allows network operators to deploy high-speed 100GbE connectivity without requiring the physical space associated with larger optical modules.
Data Center Networking
The 57-1000352-01 is particularly suitable for data-center networking environments that require high bandwidth over relatively short distances.
- Leaf-to-spine connectivity
- Data-center switch interconnects
- High-speed server uplinks
- Aggregation links
- Core network connections
- High-performance computing infrastructure
100GBASE-ESR4 vs 100GBASE-LR4
| Feature |
Brocade 57-1000352-01 ESR4 |
Typical 100GBASE-LR4 |
| Data Rate |
100Gb/s |
100Gb/s |
| Form Factor |
QSFP28 |
QSFP28 |
| Optical Medium |
Multimode Fiber |
Single-Mode Fiber |
| Wavelength |
850nm class |
1310nm class |
| Reach |
Up to 300m |
Typically up to 10km |
| Connector |
MTP/MPO |
Duplex LC |
| Primary Use |
Short-range data-center links |
Longer-distance network links |
Compatibility Considerations
The 57-1000352-01 should be installed only in networking equipment that supports the appropriate Brocade 100G QSFP28 optical module and 100GBASE-ESR4 specification.
- Verify QSFP28 port compatibility
- Verify 100GbE support
- Confirm transceiver coding requirements
- Use compatible multimode fiber
- Verify MTP/MPO connector compatibility
- Confirm fiber polarity
- Check switch firmware and supported optics
Optical modules can be vendor-coded for specific networking platforms. Always verify compatibility with the exact switch, router or server adapter before deployment.
High-Bandwidth Data Center Applications
100GbE connectivity is useful for applications that generate significant east-west traffic within modern data centers. The Brocade ESR4 optic provides a short-range optical option for connecting compatible 100GbE equipment.
It can be deployed in environments supporting virtualization, cloud infrastructure, high-performance storage, distributed applications and other bandwidth-intensive workloads.
Benefits
- 100Gb/s optical networking
- Compact QSFP28 form factor
- 100GBASE-ESR4 support
- 850nm multimode optics
- Up to 300m reach
- MTP/MPO multifiber connectivity
- High port density
- Ideal for data-center networks
- Suitable for high-bandwidth interconnects
- Designed for compatible Brocade networking platforms
Why Buy from Datacom Technologies (BD)?
Datacom Technologies (BD) supplies Brocade optical transceivers, QSFP/QSFP28 modules, Ethernet switches, data-center networking equipment and enterprise infrastructure products in Bangladesh. Customers can receive competitive pricing, technical consultation, deployment assistance and nationwide delivery.
- Call/WhatsApp: +8801748173213
- Email: sales@datacom.com.bd
- Alternative Email: datacomtechnologiesbd@gmail.com
- Office: Tropical Center, 218, Dr. Kudroti Khuda Road, New Elephant Road, Dhaka-1205, Bangladesh
Frequently Asked Questions (FAQ)
Q1: What is Brocade 57-1000352-01?
It is a Brocade 100GBASE-ESR4 QSFP28 optical transceiver designed for 100GbE short-range multimode fiber networking.
Q2: What is the data rate?
The module is designed for 100Gb/s Ethernet connectivity.
Q3: What is the form factor?
It uses the QSFP28 form factor.
Q4: What optical standard does it use?
The 57-1000352-01 is identified as a 100GBASE-ESR4 optic, with Brocade product identifier 100G-QSFP-ESR4. :contentReference[oaicite:5]{index=5}
Q5: What wavelength does the transceiver use?
The ESR4 module operates in the 850nm optical range.
Q6: What is the maximum transmission distance?
Brocade documentation specifies up to 300m over multimode fiber. :contentReference[oaicite:6]{index=6}
Q7: What type of fiber does it use?
It is designed for multimode fiber (MMF).
Q8: What connector does it use?
Brocade documentation identifies the optic with an MTP 1x8 or 1x12 interface. :contentReference[oaicite:7]{index=7}
Q9: Is 57-1000352-01 suitable for single-mode fiber?
No. It is a short-range multimode 100GBASE-ESR4 optic. For long-distance single-mode links, a compatible LR4 or other SMF optic should be selected instead.
Q10: Can it be used for switch-to-switch connectivity?
Yes, provided both networking devices support compatible 100GbE QSFP28 optics and the required MTP/MPO multimode fiber infrastructure.
Q11: Is this the same as 100GBASE-SR4?
No. Both are short-range multimode 100G technologies, but the 57-1000352-01 is specifically identified as 100GBASE-ESR4 and supports up to 300m according to Brocade documentation. :contentReference[oaicite:8]{index=8}
