About Extreme Networks 10320-AO 40GBase-LR4 10km TAA-Compatible QSFP+ Transceiver in Bangladesh
The Extreme Networks 10320-AO is a TAA-compliant, Extreme Networks 10320-compatible 40GBase-LR4 QSFP+ transceiver designed for high-speed Ethernet connectivity over single-mode fiber. It supports transmission distances of up to 10km using a duplex LC connector and CWDM wavelengths from 1270nm to 1330nm.
The 10320-AO uses a QSFP+ form factor and supports 40-Gigabit Ethernet. It includes Digital Optical Monitoring (DOM) for access to real-time operating parameters and is designed for hot-plug installation in compatible networking equipment. The manufacturer specification also identifies compliance with QSFP+ MSA/SFF-8436 requirements. :contentReference[oaicite:2]{index=2}
Extreme Networks 10320-AO 40GBase-LR4 QSFP+ Specifications & Features
| Specification | Details |
|---|
| Brand / Compatibility | Extreme Networks 10320 Compatible |
| Part Number | 10320-AO |
| Form Factor | QSFP+ |
| Ethernet Speed | 40GbE |
| Transceiver Type | 40GBase-LR4 |
| Fiber Type | Single-Mode Fiber (SMF) |
| Maximum Reach | 10km |
| Wavelength | 1270nm to 1330nm |
| Connector | Duplex LC |
| Digital Optical Monitoring | DOM Supported |
| Operating Temperature | 0°C to 70°C |
| Hot-Pluggable | Yes |
| TAA Compliant | Yes |
| MSA Compliance | QSFP+ MSA / SFF-8436 |
Overview
The Extreme Networks 10320-AO is designed to provide 40GbE connectivity for compatible Extreme Networks networking equipment. Its LR4 optical design uses multiple CWDM wavelengths over single-mode fiber to provide up to 10km of network reach.
The transceiver uses a compact QSFP+ form factor and a duplex LC optical interface, making it suitable for high-speed data-center and enterprise backbone connections where LC-based single-mode fiber infrastructure is already deployed.
Buy Extreme Networks 10320-AO 40GBase-LR4 QSFP+ Transceiver in Bangladesh
Purchase the Extreme Networks 10320-AO 40GBase-LR4 10km TAA-compatible QSFP+ transceiver from Datacom Technologies (BD). We supply Extreme Networks-compatible optical transceivers, SFP/SFP+, QSFP/QSFP+ and QSFP28 modules for enterprise networking, data centers and high-performance network infrastructure in Bangladesh.
Key Features
- 40GBase-LR4 optical connectivity
- Up to 10km transmission distance
- Single-Mode Fiber (SMF) support
- 1270nm to 1330nm wavelength range
- Duplex LC connector
- QSFP+ form factor
- 40GbE data rate
- Digital Optical Monitoring (DOM)
- Hot-pluggable design
- 0°C to 70°C commercial operating temperature
- TAA compliant
- QSFP+ MSA / SFF-8436 compliant
- RoHS compliant and lead-free
Applications
- 40Gb Ethernet
- Enterprise network backbones
- Data center interconnects
- High-speed aggregation networks
- Server-to-switch connectivity
- Core network connectivity
- Data center switching
- Enterprise LAN infrastructure
- High-performance computing environments
- Long-distance intra-campus networking
40GbE High-Speed Connectivity
The 10320-AO provides 40-Gigabit Ethernet connectivity in a QSFP+ form factor. Its 40GBase-LR4 interface is designed for high-bandwidth network links between compatible switches, routers and other network devices.
40GbE connectivity is suitable for aggregation and backbone applications where 10GbE links may no longer provide sufficient bandwidth.
40GBase-LR4 Technology
The LR4 optical architecture uses multiple wavelengths over a single-mode fiber connection. The 10320-AO operates across the 1270nm to 1330nm wavelength range and supports a maximum reach of up to 10km. :contentReference[oaicite:3]{index=3}
The four CWDM channels are associated with approximately 1271nm, 1291nm, 1311nm and 1331nm optical wavelengths. :contentReference[oaicite:4]{index=4}
10km Single-Mode Fiber Transmission
The 10320-AO is designed for up to 10km transmission over Single-Mode Fiber (SMF). This makes it suitable for longer-distance connections between network devices compared with short-reach multimode 40GbE transceivers.
Actual achievable distance depends on the fiber plant, optical loss, connectors, patch panels, environmental conditions and the specifications of the equipment at both ends.
Duplex LC Connector
The 10320-AO uses a duplex LC connector. LC connectivity provides a compact optical interface suitable for high-density network environments.
Because this is an LR4 transceiver designed for single-mode fiber, the connected fiber infrastructure should be compatible with the module's optical specifications.
Digital Optical Monitoring (DOM)
The transceiver supports Digital Optical Monitoring (DOM), allowing compatible network equipment to access real-time optical operating parameters. DOM can assist network administrators with monitoring module health and optical link conditions. :contentReference[oaicite:5]{index=5}
Hot-Pluggable QSFP+ Design
The 10320-AO is designed as a hot-pluggable QSFP+ module. This enables installation and replacement in compatible networking hardware without requiring the complete network device to be powered down, subject to the host platform's supported procedures.
Always follow the installation and removal procedures recommended by the networking equipment manufacturer.
TAA Compliance
The 10320-AO is identified as Trade Agreements Act (TAA) compliant. TAA compliance can be an important procurement requirement for certain U.S. government and regulated deployments. :contentReference[oaicite:6]{index=6}
QSFP+ MSA Compliance
The transceiver is designed around QSFP+ Multi-Source Agreement requirements and SFF-8436 compliance. MSA-based interoperability helps standardize the physical and electrical characteristics of compatible QSFP+ modules. :contentReference[oaicite:7]{index=7}
Commercial Temperature Operation
The 10320-AO is specified for a commercial operating temperature range of 0°C to 70°C. This makes it appropriate for typical controlled enterprise network rooms and data-center environments. :contentReference[oaicite:8]{index=8}
Extreme Networks Compatibility
The 10320-AO is specifically designed as an Extreme Networks 10320-compatible transceiver. The manufacturer identifies Extreme Networks as the compatible OEM and 10320 as the corresponding OEM part number. :contentReference[oaicite:9]{index=9}
Compatibility should still be verified against the exact switch, router or network platform, firmware version and optical configuration before deployment.
40GBase-LR4 vs 40GBase-SR4
| Feature |
40GBase-LR4 |
40GBase-SR4 |
| Typical Fiber |
Single-Mode Fiber |
Multimode Fiber |
| Connector |
Duplex LC |
Usually MPO/MTP |
| Reach |
Up to 10km |
Shorter data-center distances |
| Typical Use |
Longer-distance enterprise/data-center links |
Short-range data-center links |
| Wavelength |
1270nm to 1330nm |
850nm class |
Fiber Compatibility
The 10320-AO is designed specifically for Single-Mode Fiber (SMF). It should be paired with suitable single-mode fiber cabling and a compatible LR4 optical module at the opposite end of the link.
- Single-Mode Fiber required
- Duplex LC optical connection
- Compatible 40GBase-LR4 equipment recommended
- Optical link budget should be considered
- Connector cleanliness should be maintained
- Fiber polarity should be correctly configured
Data Center Networking
The 10320-AO is well suited to data-center networking applications requiring 40GbE connectivity over longer distances. It can be deployed for switch-to-switch, aggregation and backbone links where single-mode fiber infrastructure is available.
Its 10km reach provides considerably more distance than typical short-range 40GbE optical solutions, making it useful for connections between network rooms, buildings or extended data-center environments where supported.
Enterprise Backbone Connectivity
40GBase-LR4 can be used in enterprise backbone and aggregation environments to consolidate multiple lower-speed links into higher-bandwidth network connections.
The 10320-AO combines 40GbE throughput with 10km single-mode fiber reach, making it appropriate for high-bandwidth uplinks and network interconnect applications.
DOM Monitoring and Network Maintenance
DOM support provides network administrators with visibility into supported optical parameters. This can be useful for troubleshooting, proactive maintenance and monitoring optical link conditions.
DOM availability and the specific parameters displayed depend on the host networking equipment.
Benefits
- 40GbE high-speed connectivity
- 10km single-mode fiber reach
- 40GBase-LR4 optical technology
- 1270nm to 1330nm wavelength range
- Duplex LC connectivity
- QSFP+ high-density form factor
- Digital Optical Monitoring support
- Hot-pluggable design
- TAA compliant
- QSFP+ MSA / SFF-8436 compliant
- Suitable for enterprise and data-center networks
Why Buy from Datacom Technologies (BD)?
Datacom Technologies (BD) supplies Extreme Networks-compatible optical transceivers, QSFP+ modules, SFP/SFP+ transceivers, enterprise networking equipment and data-center connectivity solutions in Bangladesh. Customers can receive competitive pricing, technical consultation, configuration assistance and nationwide delivery.
- Call/WhatsApp: +8801748173213
- Email: sales@datacom.com.bd
- Alternative Email: datacomtechnologiesbd@gmail.com
- Office: Tropical Center, 218, Dr. Kudroti Khuda Road, New Elephant Road, Dhaka-1205, Bangladesh
Frequently Asked Questions (FAQ)
Q1: What is the Extreme Networks 10320-AO?
The 10320-AO is an Extreme Networks 10320-compatible TAA-compliant 40GBase-LR4 QSFP+ transceiver designed for up to 10km transmission over single-mode fiber.
Q2: What network speed does 10320-AO support?
It supports 40-Gigabit Ethernet / 40GBase-LR4 connectivity.
Q3: What is the maximum transmission distance?
The specified maximum reach is up to 10km over compatible single-mode fiber.
Q4: What type of fiber does 10320-AO use?
It uses Single-Mode Fiber (SMF).
Q5: What wavelength does 10320-AO use?
The specified wavelength range is 1270nm to 1330nm, using four CWDM channels.
Q6: What connector does it use?
The transceiver uses a duplex LC connector.
Q7: Does 10320-AO support DOM?
Yes. The module supports Digital Optical Monitoring (DOM) for compatible host equipment.
Q8: Is 10320-AO hot-pluggable?
Yes. The module is designed as a hot-pluggable QSFP+ transceiver.
Q9: Is 10320-AO TAA compliant?
Yes. The manufacturer specification identifies the 10320-AO as TAA compliant.
Q10: What is the operating temperature?
The specified commercial operating temperature range is 0°C to 70°C.
Q11: Is 10320-AO compatible with Extreme Networks?
Yes. It is specifically designed as a compatible replacement for Extreme Networks OEM part number 10320.
Q12: What is the difference between LR4 and SR4?
LR4 is designed for longer-distance transmission over single-mode fiber and uses LC connectivity, while SR4 is intended primarily for short-range multimode-fiber data-center connections.
Q13: Is 10320-AO suitable for data centers?
Yes. Its 40GbE speed, 10km SMF reach, QSFP+ form factor and DOM support make it suitable for supported enterprise and data-center networking applications.
Q14: Is 10320-AO MSA compliant?
Yes. The product documentation identifies QSFP+ MSA/SFF-8436 compliance.
Q15: Where can I buy Extreme Networks 10320-AO in Bangladesh?
You can contact Datacom Technologies (BD) for Extreme Networks-compatible QSFP+ transceivers, optical networking products and enterprise network hardware with competitive pricing and nationwide delivery.
