H3C S5560X-54F-EI Gigabit Ethernet Switch

H3C S5560X-54F-EI Gigabit Ethernet Switch

Specification

Specification	Details
Model	S5560X-54F-EI
Ports	48 × SFP ports, 4 × 10G SFP+ ports
Expansion Slot	1 expansion slot supporting various interface modules, including: - 2-port 40GE QSFP+ interface module - 2-port 10G SFP+ interface module - 8-port 10G SFP+ interface module - 2-port 25G SFP28 interface module
Switching Capacity	598 Gbps
Packet Forwarding Rate	252 Mpps
Dimensions (W × D × H)	440 mm × 360 mm × 43.6 mm
Weight	≤ 6.7 kg
Management Ports	1 × RJ-45 Console port, 1 × Micro USB Console port (cannot work simultaneously; Micro USB has priority)
Power Supply	Supports dual modular power supplies: - AC: 100V–240V AC, 50/60Hz - DC: -48V–-60V DC
Power Consumption	Static: 30W (single AC/DC); Full load: 130W (single AC), 132W (single DC)
Operating Temperature	-5°C to 45°C
Operating Humidity	5% to 95% (non-condensing)

Description: The H3C S5560X-54F-EI is part of the S5560X-EI series of intelligent, scalable Gigabit Ethernet switches. Designed to deliver exceptional performance and flexibility, this switch is equipped with 48 SFP ports and 4 additional 10G SFP+ ports, providing high-density fiber connectivity suitable for various enterprise applications. One of the standout features of the S5560X-54F-EI is its modular design, which includes a single expansion slot. This slot supports a variety of interface modules, such as 2-port 40GE QSFP+, 2-port 10G SFP+, 8-port 10G SFP+, and 2-port 25G SFP28 modules. This modularity allows businesses to customize the switch's port configuration to meet specific networking requirements, ensuring scalability and adaptability to future network expansions. The switch boasts a substantial switching capacity of 598 Gbps and a packet forwarding rate of 252 Mpps, ensuring efficient data processing and minimal latency. Its robust hardware architecture is complemented by H3C's state-of-the-art Comware 7 operating system, which enhances the switch's performance and reliability. For management and maintenance, the S5560X-54F-EI offers both RJ-45 and Micro USB console ports, providing flexibility in administrative access. However, it's important to note that these console ports cannot operate simultaneously, with the Micro USB port taking priority when both are connected. This design consideration ensures secure and efficient management of the switch. The switch supports dual modular power supplies, accommodating both AC (100V–240V AC, 50/60Hz) and DC (-48V–-60V DC) inputs. This redundancy in power supply options enhances the switch's reliability and ensures continuous operation even in the event of a power supply failure. The power consumption is efficient, with a static consumption of 30W (single AC/DC) and a full-load consumption of 130W (single AC) or 132W (single DC), reflecting its energy-efficient design. In terms of environmental adaptability, the S5560X-54F-EI operates effectively within a temperature range of -5°C to 45°C and a relative humidity of 5% to 95% (non-condensing). This wide operating range makes it suitable for deployment in diverse environmental conditions, from standard office settings to more demanding industrial environments. The S5560X-54F-EI is equipped with advanced features such as VXLAN (Virtual eXtensible LAN) technology, which facilitates network virtualization and supports the creation of scalable and isolated network segments. It also supports H3C's Intelligent Resilient Framework 2 (IRF2), enabling the virtualization of multiple switches into a single logical device. This capability simplifies network management and enhances the network's resilience and flexibility.

Key Features:

• High Performance and Density: Provides 48 10GE SFP+ ports and 6 40GE QSFP+ ports. Supports wire-speed forwarding and non-blocking architecture. Enhanced hardware-based forwarding and support for advanced Layer 2 and Layer 3 features.
• Advanced Layer 3 Features: Supports comprehensive IPv4 and IPv6 routing protocols. Offers BGP, OSPF, IS-IS, and static routing support. Enables seamless integration into complex networks.
• Robust Security Features: Offers multi-layer security policies including ACL, MAC-based authentication, and port security. Supports DHCP snooping, IP source guard, and ARP inspection. Includes DoS attack defense and CPU protection policies.
• Intelligent Management: Provides CLI, Web-based GUI, and SNMP-based network management. Supports NetStream for traffic analysis and monitoring. Remote maintenance and troubleshooting capabilities.
• High Availability and Reliability: Supports Ethernet Ring Protection Switching (ERPS) and Virtual Router Redundancy Protocol (VRRP). Redundant power supplies and fan modules. Graceful restart (GR) and Bidirectional Forwarding Detection (BFD) support.

Where It Can Be Used:

• Data Centers: Acts as an aggregation or core switch for high-density data center environments.
• Enterprise Networks: Suitable for large enterprises needing high-speed backbone switching.
• Service Providers: Ideal for delivering high-speed connectivity and seamless service delivery.
• Campus Networks: Offers reliable connectivity and redundancy for large campus deployments.

Installation Steps:

1. Unpacking and Inspection: Verify the contents of the package. Check for any physical damage.
2. Rack Mounting: Attach the mounting brackets to the switch. Mount the switch in the rack securely.
3. Connecting the Cables: Connect power cables to the redundant power supply units. Connect Ethernet or fiber optic cables to the appropriate ports.
4. Powering On: Turn on the switch and verify LED indicators.
5. Configuration: Connect to the console port via a serial cable. Use CLI or web interface for initial configuration. Set IP addresses, VLANs, and routing protocols.
6. Testing and Verification: Run diagnostic commands to check connectivity and performance. Monitor traffic and CPU utilization.

User Experience:

• Reliable Performance: Handles large volumes of data efficiently.
• Easy Management: Web GUI and CLI offer intuitive control and configuration.
• Robust Security: Keeps network traffic secure and prevents intrusions.
• Minimal Downtime: Redundant design and high availability reduce downtime risk.

Why Choose H3C S5560X-54F-EI Gigabit Ethernet Switch?

1. High Capacity and Speed: Ideal for high-demand environments.
2. Advanced Routing and Switching Capabilities: Supports complex Layer 3 protocols.
3. Comprehensive Security Features: Safeguards the network against threats.
4. Intelligent Network Management: Simplifies monitoring and maintenance.
5. Reliable and Scalable: Meets the demands of growing networks.

Buy H3C S5560X-54F-EI Gigabit Ethernet Switch from Datacom BD

Get the original H3C S5560X-54F-EI Gigabit Ethernet Switch in Bangladesh from Datacom BD. We offer a wide range of the latest Gigabit Ethernet Switch at competitive prices. Order online or visit our office to get yours at the best price. This H3C Gigabit Ethernet Switch comes with a 3-years warranty.
