ADVA 61004008 DOM Transceiver Module

About ADVA 61004008 1000BASE-SX 850nm 550m SFP DOM Optical Transceiver in Bangladesh

The ADVA 61004008 is a 1.25Gbps 1000BASE-SX SFP optical transceiver designed for compatible ADVA optical networking equipment. It operates at 850nm over multimode fiber and provides connectivity for Gigabit Ethernet links with a specified reach of up to 550 meters on OM3 fiber.

The module uses a standard duplex LC optical connector and supports Digital Optical Monitoring (DOM), allowing compatible equipment to monitor important transceiver operating parameters. Current ADVA-compatible product catalogs consistently identify part number 61004008 as a 1000BASE-SX, 850nm, 550m MMF SFP. ([ENET Solutions](https://www.enetusa.com/products/optical-transceivers/adva))

ADVA 61004008 SFP Specifications & Features

Overview

The ADVA 61004008 provides reliable Gigabit Ethernet connectivity for short-distance fiber networks. Its 850nm multimode architecture is designed for high-speed connections inside data centers, enterprise networks, telecommunications facilities and other controlled networking environments.

With up to 550 meters of reach on OM3 multimode fiber, the 61004008 is suitable for switch-to-switch, switch-to-server and equipment interconnects where single-mode long-distance optics are unnecessary.

Buy ADVA 61004008 SFP Module in Bangladesh

Purchase the ADVA 61004008 1000BASE-SX 850nm 550m SFP DOM Optical Transceiver from Datacom Technologies (BD). We supply ADVA-compatible optical transceivers, SFP/SFP+ modules, fiber networking products and enterprise telecommunications equipment in Bangladesh with competitive pricing, technical consultation and nationwide delivery.

Key Features

• ADVA part number 61004008
• 1.25Gbps Gigabit Ethernet
• 1000BASE-SX support
• 850nm optical wavelength
• Multimode fiber operation
• Up to 550m reach on OM3 fiber
• Duplex LC connector
• SFP form factor
• DOM/DDM monitoring support
• Suitable for compatible ADVA equipment
• Short-range Gigabit Ethernet connectivity

Applications

• ADVA Optical Networking Equipment
• Gigabit Ethernet Networks
• Data Center Connectivity
• Enterprise LAN Networks
• Switch-to-Switch Links
• Switch-to-Server Links
• Campus Network Connectivity
• Telecommunications Networks
• Fiber-Based Access Networks

1000BASE-SX Connectivity

The 61004008 uses the 1000BASE-SX standard for Gigabit Ethernet over multimode optical fiber. SX optics operate in the 850nm wavelength range and are optimized for short-distance fiber connectivity.

This makes the module particularly appropriate for environments where fiber runs are within the optical budget of the 1000BASE-SX specification.

850nm Optical Wavelength

The ADVA 61004008 operates at 850nm. This wavelength is commonly used with multimode fiber for Gigabit Ethernet and provides a cost-effective solution for short-range optical networking.

Multimode Fiber Support

The module is designed for multimode fiber (MMF). Current product specifications identify a maximum distance of up to 550 meters on OM3 fiber. ([GBICS](https://gbics.com/61004008-adva-compatible-1000base-sx-sfp-850nm-550m-dom-transceiver-module/))

Actual transmission distance depends on the installed fiber grade, modal bandwidth, connector losses, patch-panel losses and the optical characteristics of the connected devices.

Duplex LC Connector

The 61004008 uses a duplex LC connector, providing separate optical paths for transmission and reception.

Use compatible duplex LC multimode fiber patch cables and maintain correct fiber polarity when installing the module.

Digital Optical Monitoring

The 61004008 is specified with DOM support. Digital Optical Monitoring allows compatible host equipment to retrieve diagnostic information from the transceiver.

Depending on the ADVA platform, available monitoring information may include module temperature, supply voltage, optical transmit power and optical receive power.

550m OM3 Reach

The 550-meter specification makes the ADVA 61004008 suitable for many intra-building and data center fiber links. OM3 multimode fiber provides the appropriate bandwidth characteristics for this type of 1GbE optical connection.

For longer links, a single-mode optic such as a 1000BASE-LX/LH module should be considered instead.

ADVA 61004008 vs 61004009

ADVA-compatible catalogs list 61004008 as the 1000BASE-SX 850nm short-range optic and 61004009 as the 1000BASE-LX/LH 1310nm 10km optic. :contentReference[oaicite:1]{index=1}

Compatibility

ADVA 61004008 is a vendor-specific transceiver part number. Current compatibility catalogs identify 61004008 as an ADVA-compatible 1000BASE-SX SFP and state that it is intended for ADVA products supporting this transceiver. ([GBICS](https://gbics.com/61004008-adva-compatible-1000base-sx-sfp-850nm-550m-dom-transceiver-module/))

Before purchasing a replacement, verify the exact ADVA equipment model and supported transceiver list. Although 1000BASE-SX is an industry-standard optical specification, vendor coding and host-device compatibility can affect interoperability.

Optical Link Planning

For reliable Gigabit Ethernet operation, the complete optical path should be checked before deployment.

• OM3 or compatible multimode fiber
• Fiber length
• Modal bandwidth
• Connector insertion loss
• Patch-panel losses
• Fiber polarity
• Optical power budget
• ADVA host compatibility

Benefits

• 1.25Gbps Gigabit Ethernet connectivity
• 1000BASE-SX support
• 850nm multimode optics
• Up to 550m on OM3 fiber
• Duplex LC connectivity
• Compact SFP form factor
• DOM/DDM monitoring
• Suitable for compatible ADVA equipment
• Ideal for short-distance enterprise and data center links

Why Buy from Datacom Technologies (BD)?

Datacom Technologies (BD) supplies ADVA optical transceivers, SFP/SFP+ modules, fiber networking components, telecommunications equipment and enterprise networking hardware in Bangladesh. Customers can receive competitive pricing, technical consultation, deployment assistance and nationwide delivery.

• Call/WhatsApp: +8801748173213
• Email: sales@datacom.com.bd
• Alternative Email: datacomtechnologiesbd@gmail.com
• Office: Tropical Center, 218, Dr. Kudroti Khuda Road, New Elephant Road, Dhaka-1205, Bangladesh

Frequently Asked Questions (FAQ)

Q1: What is ADVA 61004008?
ADVA 61004008 is a 1000BASE-SX 850nm SFP optical transceiver designed for compatible ADVA networking equipment.

Q2: What is the data rate?
The module operates at 1.25Gbps for Gigabit Ethernet applications.

Q3: What wavelength does 61004008 use?
It uses an 850nm optical wavelength.

Q4: What is the maximum reach?
The module is specified for up to 550 meters on OM3 multimode fiber. ([GBICS](https://gbics.com/61004008-adva-compatible-1000base-sx-sfp-850nm-550m-dom-transceiver-module/))

Q5: Does it use single-mode or multimode fiber?
It uses multimode fiber (MMF).

Q6: What connector does it use?
It uses a duplex LC connector.

Q7: Does 61004008 support DOM?
Yes. Current ADVA-compatible listings specify DOM support.

Q8: Is 61004008 a 1G SFP or 10G SFP+?
It is a 1Gbps-class SFP for 1000BASE-SX, not a 10Gbps SFP+ module.

Q9: Can I use 61004008 over single-mode fiber?
It is designed for 850nm multimode-fiber operation. For single-mode and longer-distance links, an appropriate 1000BASE-LX/LH or other SMF optic should be selected.

Q10: Is 61004008 compatible with any SFP port?
Not necessarily. The host equipment must support the appropriate 1000BASE-SX optic and vendor compatibility. Verify the exact ADVA platform before installation.

Q11: What is the difference between ADVA 61004008 and 61004009?
61004008 is a 1000BASE-SX 850nm MMF optic with up to 550m OM3 reach, while 61004009 is a 1000BASE-LX/LH 1310nm SMF optic with up to 10km reach.

Q12: Where can I buy ADVA 61004008 in Bangladesh?
You can contact Datacom Technologies (BD) for ADVA SFP modules, optical transceivers, fiber networking products and enterprise telecommunications equipment with competitive pricing and nationwide delivery.
