Aruba AP-654 Wi-Fi 6E Indoor Access Point – 6 GHz Band, Bluetooth 5, 2.5 Gbps Port

The HPE Aruba Networking AP-654 is a high-performance Wi-Fi 6E indoor campus access point designed for enterprise wireless networks, high-density environments, and bandwidth-intensive applications. It provides tri-band connectivity across the 2.4GHz, 5GHz, and 6GHz spectrum with three 4x4 MIMO radios.

The Aruba AP-654 combines Wi-Fi 6E performance with external antenna flexibility, Bluetooth 5.0 IoT connectivity, a 2.5GbE Smart Rate Ethernet port, USB connectivity, and advanced enterprise security. It is well suited for offices, education, healthcare, retail, and other demanding indoor wireless deployments.

Aruba AP-654 Wi-Fi 6E Key Features

• Wi-Fi 6E based on IEEE 802.11ax with dedicated 6GHz spectrum support.
• Tri-radio 4x4 MIMO architecture across 2.4GHz, 5GHz, and 6GHz bands.
• Up to 7.8 Gbps maximum aggregate wireless data rate.
• External antenna design provides flexible RF planning and coverage optimization.
• 2.5GbE Smart Rate Ethernet port provides high-speed wired connectivity.
• Integrated Bluetooth 5.0 and Zigbee support for enterprise IoT applications.
• USB 2.0 Type-A interface supports compatible peripherals and extensions.
• Supports 160MHz channels on the 5GHz and 6GHz radios where permitted.
• OFDMA and MU-MIMO improve efficiency in high-density client environments.
• WPA3 and enhanced enterprise security features help protect wireless communications.

Aruba AP-654 Technical Specifications

Aruba AP-654 Wi-Fi 6E Performance

The Aruba AP-654 uses Wi-Fi 6E technology to extend enterprise Wi-Fi into the 6GHz spectrum. Its three 4x4 MIMO radios provide simultaneous 2.4GHz, 5GHz, and 6GHz connectivity and support an aggregate data rate of up to 7.8 Gbps.

The additional 6GHz spectrum provides access to wider and less congested channels for compatible Wi-Fi 6E client devices. This makes the AP-654 suitable for bandwidth-intensive applications, cloud services, high-definition video, and real-time collaboration.

Aruba AP-654 6 GHz Connectivity

The dedicated 6GHz radio provides additional wireless spectrum for supported Wi-Fi 6E devices. Up to 160MHz channel widths can be used where supported by the local regulatory domain and network configuration.

Actual wireless performance depends on client capabilities, channel availability, RF conditions, regulatory restrictions, distance, interference, and network utilization.

Aruba AP-654 External Antenna Design

The AP-654 uses an external antenna architecture, allowing network administrators to select appropriate antenna options based on the required coverage area, mounting environment, RF characteristics, and deployment requirements.

This makes the AP-654 suitable for enterprise installations where greater control over antenna configuration and wireless coverage is required.

Aruba AP-654 Bluetooth and IoT

The AP-654 includes integrated Bluetooth Low Energy and Zigbee capabilities for enterprise IoT applications. These capabilities can support compatible asset tracking, smart-building, location, sensor, and connected-device deployments.

The integrated USB interface provides an additional expansion option for supported peripherals and accessories.

Aruba AP-654 2.5GbE Connectivity

A 2.5GbE Smart Rate Ethernet port provides high-speed wired connectivity between the access point and the enterprise network. The interface supports 100Mbps, 1Gbps, and 2.5Gbps Ethernet operation.

Power over Ethernet simplifies installation by allowing both network connectivity and electrical power to be delivered through the Ethernet connection.

Aruba AP-654 Applications

• Enterprise office wireless networks
• Corporate campus deployments
• Universities and educational institutions
• Healthcare facilities
• Retail and commercial environments
• High-density indoor Wi-Fi 6E deployments
• Cloud-based business applications
• High-definition video and collaboration
• IoT and smart-building deployments
• Bluetooth and Zigbee applications

Aruba AP-654 Compatibility

The AP-654 is part of the HPE Aruba Networking 650 Series Campus Access Points and is designed for enterprise Aruba wireless environments. It supports centralized management through HPE Aruba Networking Central and compatible Aruba networking architectures.

Because the AP-654 uses external antennas and operates in the 6GHz spectrum, the correct regional SKU, antenna, and regulatory configuration should be selected for the intended deployment location.

Aruba AP-654 Indoor Deployment

The Aruba AP-654 is designed as an indoor campus access point. It is suitable for offices, classrooms, healthcare environments, retail facilities, and other indoor enterprise locations where high wireless capacity and 6GHz connectivity are required.

Aruba AP-654 Price in Bangladesh

The Aruba AP-654 price in Bangladesh depends on the regional SKU, external antenna requirements, licensing, accessories, warranty configuration, and current distributor pricing. Contact Datacom Technologies (BD) for the latest Aruba AP-654 price and availability in Bangladesh.

Email: sales@datacom.com.bd

Why Choose Aruba AP-654?

• Wi-Fi 6E technology provides access to the additional 6GHz spectrum.
• Tri-radio 4x4 MIMO architecture delivers high-capacity wireless performance.
• Up to 7.8 Gbps aggregate data rate across the three wireless radios.
• External antenna architecture provides flexible RF deployment options.
• 2.5GbE Smart Rate Ethernet supports high-speed wired connectivity.
• Integrated Bluetooth and Zigbee support makes the AP suitable for enterprise IoT.
• USB connectivity provides expansion capabilities for supported peripherals.
• OFDMA and MU-MIMO improve wireless efficiency in high-density environments.
• Enterprise-grade WPA3 and advanced network security capabilities.
• Ideal for modern indoor enterprise and campus Wi-Fi 6E deployments.

For Aruba AP-654 Wi-Fi 6E Indoor Access Point price in Bangladesh, external antenna selection, product consultation, and enterprise wireless deployment support, contact Datacom Technologies (BD) at sales@datacom.com.bd.
