Cisco C9800-L-F-K9 Catalyst 9800-L Wireless Controller with Fiber Uplink
The Cisco C9800-L-F-K9 is a Catalyst 9800-L Series enterprise wireless LAN controller designed to centrally manage Cisco wireless access points, WLAN policies, security, mobility, and network operations. This model is the fiber-uplink version of the Catalyst 9800-L Wireless Controller and provides two 10G/Multigigabit fiber uplinks.
The C9800-L-F-K9 is suitable for enterprise campuses, branch networks, education, hospitality, healthcare, and other organizations requiring centralized Cisco wireless infrastructure management. The base platform supports up to 250 access points and 5,000 clients, while the optional performance license can increase capacity to 500 access points and 10,000 clients.
Key Features of Cisco C9800-L-F-K9
- Cisco Catalyst 9800-L Series Wireless LAN Controller
- Fiber uplink configuration
- 2 × 10G/Multigigabit fiber uplinks
- Base support for up to 250 access points
- Base support for up to 5,000 wireless clients
- Optional performance upgrade for up to 500 APs and 10,000 clients
- Up to 5 Gbps base throughput
- Up to 10 Gbps throughput with the Performance license under applicable conditions
- Cisco IOS XE software platform
- Supports centralized, FlexConnect, and fabric deployment modes
Technical Specifications
| Brand |
Cisco |
| Model |
C9800-L-F-K9 |
| Series |
Cisco Catalyst 9800-L |
| Product Type |
Wireless LAN Controller |
| Uplink Type |
Fiber |
| Fixed Uplinks |
2 × 10G/Multigigabit fiber |
| Base AP Capacity |
Up to 250 access points |
| Base Client Capacity |
Up to 5,000 clients |
| Base Throughput |
Up to 5 Gbps |
| Performance License |
LIC-C9800L-PERF |
| Performance License Capacity |
Up to 500 APs and 10,000 clients |
| Performance Throughput |
Up to 10 Gbps under applicable conditions |
| Maximum WLANs |
4096 |
| Maximum VLANs |
4096 |
| Form Factor |
1RU; half-width chassis |
| Power Supply |
110W, 12V DC AC/DC adapter |
| Software |
Cisco IOS XE |
| Management |
Cisco DNA Center, Cisco Prime Infrastructure, and open-standard APIs |
Fiber Uplink Connectivity
The C9800-L-F-K9 is specifically the fiber-uplink version of the Catalyst 9800-L. Cisco specifies two 10G/Multigigabit fiber uplinks for this model, allowing the controller to connect to compatible enterprise switching infrastructure using supported fiber transceivers. The exact SFP/SFP+ module and cabling configuration should be selected according to the required speed, fiber type, distance, and connected switch.
Centralized Wireless Management
The Catalyst 9800-L provides centralized control of compatible Cisco wireless access points. Network administrators can use the controller for WLAN configuration, wireless security, access-point management, mobility, monitoring, and policy enforcement across the wireless environment.
Wireless Capacity
The base Catalyst 9800-L supports up to 250 access points and 5,000 clients with up to 5 Gbps throughput. Cisco's optional LIC-C9800L-PERF Performance license increases the supported capacity to up to 500 access points and 10,000 clients, with up to 10 Gbps throughput under the applicable performance conditions.
Deployment Modes
The Catalyst 9800-L supports multiple wireless deployment architectures, including Centralized, Cisco FlexConnect, and fabric deployment modes. The appropriate architecture depends on the organization's campus, branch, WAN, and wireless design requirements.
Licensing Information
The C9800-L-F-K9 is the wireless controller hardware PID, rather than a standalone Foundation License PID. Cisco's current ordering information identifies C9800-L-F-K9 as the base fiber-uplink controller and lists LIC-C9800L-PERF as the optional Catalyst 9800-L Performance license. Cisco also lists LIC-C9800-DTLS-K9 as an optional DTLS license.
Compatibility
The controller supports compatible Cisco wireless access points and interoperates with applicable Cisco wireless infrastructure. Cisco documentation lists support for Aironet 802.11ac Wave 1 and Wave 2 access points as well as Cisco Catalyst 9100 802.11ax access points. Actual compatibility depends on the controller software release and access-point model.
Applications
- Enterprise campus wireless networks
- Corporate office WLAN deployments
- Branch and distributed wireless networks
- Education and institutional Wi-Fi infrastructure
- Hospitality and service-sector wireless networks
- Centralized Cisco access-point management
- FlexConnect wireless deployments
- Cisco Software-Defined Access and fabric-enabled wireless environments
Why Choose Cisco C9800-L-F-K9?
- Enterprise-class Cisco Catalyst 9800 wireless controller platform
- Dedicated fiber uplink configuration
- 2 × 10G/Multigigabit fiber uplinks
- Base capacity for up to 250 APs and 5,000 clients
- Optional Performance license for larger wireless deployments
- Centralized management and policy control for Cisco wireless networks
- Compact 1RU half-width form factor
Cisco C9800-L-F-K9 Price in Bangladesh
For the latest Cisco C9800-L-F-K9 price in Bangladesh, contact Datacom Technologies (BD). Pricing and availability may vary depending on sourcing, product condition, warranty, licensing requirements, and stock status.
Contact:
sales@datacom.com.bd
Datacom Technologies (BD) can assist with sourcing Cisco wireless controllers, Catalyst access points, wireless controller licenses, performance upgrades, compatible fiber optics, and related enterprise wireless networking equipment.
