About IBM EN0H-82XX 4-Port PCIe2 Adapter
At Datacom Technologies BD, we offer a wide range of IT solutions, including the IBM EN0H-82XX 4-Port PCIe2 Adapter. This high-performance network adapter is designed to meet the demanding needs of modern businesses. With its four ports and PCIe2 interface, it provides fast and reliable network connectivity for your server. Whether you're looking to improve your network performance or upgrade your existing infrastructure, the IBM EN0H-82XX is an excellent choice. Contact us today to learn more about our products and services.
Product Specification
| Feature |
Value |
| Form Factor |
Low Profile, Regular Height |
| Interface |
PCIe 2.0 x8 |
| Ports |
2x 10Gb SFP+, 2x 1Gb RJ45 |
| Supported Transceivers |
SFP+ SR, SFP+ LR |
| Supported Protocols |
Ethernet, FCoE |
| Maximum Data Rate |
10Gbps (10Gb SFP+), 1Gbps (1Gb RJ45) |
| Power Consumption |
15W |
| Operating Temperature |
0°C to 55°C |
| Humidity |
10% to 90% (non-condensing) |
Description
The
IBM EN0H-82XX 4-Port PCIe2 Adapter is a high-performance network interface card (NIC) designed to provide efficient and reliable network connectivity for IBM servers. It offers a combination of 10 Gigabit Ethernet (10GbE) and Gigabit Ethernet (1GbE) ports, making it suitable for various network environments.
The adapter features two 10 Gigabit SFP+ ports, which can be configured with either SFP+ SR or SFP+ LR transceivers. SFP+ SR transceivers are used for short-range connections (up to 300 meters) over multimode fiber, while SFP+ LR transceivers are used for long-range connections (up to 10 kilometers) over single-mode fiber. The two 1 Gigabit RJ45 ports provide copper-based connectivity for local area networks (LANs).
The EN0H adapter supports both Ethernet and Fibre Channel over Ethernet (FCoE) protocols. This allows it to be used for both general-purpose networking and storage networking applications. FCoE enables the consolidation of Ethernet and Fibre Channel traffic onto a single network infrastructure, reducing costs and complexity.
The adapter is designed for high performance and reliability. It supports features such as link aggregation, which allows multiple physical links to be combined into a single logical channel, increasing bandwidth and redundancy. It also supports jumbo frames, which can improve network performance for certain types of traffic.
The EN0H adapter is compatible with a wide range of IBM servers and operating systems. It is a versatile and powerful NIC that can be used in various network environments, from small businesses to large data centers.
Supported/Comparable Models
IBM EN0S: Similar to the EN0H, but with a different part number.
IBM EN0T: Similar to the EN0H, but with a different part number.
IBM EN0U: Similar to the EN0H, but with a different part number.
IBM EN0V: Similar to the EN0H, but with a different part number.
How much does the IBM EN0H-82XX 4-Port PCIe2 Adapter Cost in Bangladesh?
The price of the IBM EN0H EN0H-82XX 4-Port PCIe2 Adapter can vary depending on market conditions and purchase volume. Since prices can fluctuate, they might not be listed online. However, contacting Datacom Technologies Bangladesh can get you a competitive quote based on your needs. Visit our website
Datacom Technologies (BD) or reach out through
WhatsApp: +8801748173213 or email: sales@datacomtechbd.com or datacomtechnologiesbd@gmail.com.
