Finisar FTLC1156RDPL 100Gbps 10KM QSFP28 Optical Transceiver Module
The Finisar FTLC1156RDPL is a 100Gbps QSFP28 optical transceiver designed for high-speed Ethernet connectivity over single-mode fiber. It supports 100GBASE-LR4 applications with a transmission distance of up to 10km, making it suitable for data center interconnects, enterprise networks, and high-speed backbone infrastructure.
The module uses a four-channel LAN-WDM optical architecture and a duplex LC optical interface. Its compact QSFP28 form factor provides a hot-pluggable solution for compatible 100Gbps networking equipment.
Finisar FTLC1156RDPL 100GBASE-LR4 Connectivity
The FTLC1156RDPL is designed for 100GBASE-LR4 100 Gigabit Ethernet applications. It provides an aggregate data rate of 103.1Gbps using four optical channels operating across the 1310nm wavelength band.
The four LAN-WDM channels are multiplexed into the optical link, allowing high-bandwidth 100Gbps transmission over a pair of single-mode fibers.
10KM Single-Mode Fiber Transmission
The transceiver is designed for single-mode fiber (SMF) and supports a maximum transmission distance of 10km. This makes it appropriate for extended 100GbE connections between switches, routers, aggregation equipment, and other compatible optical endpoints.
LAN-WDM Optical Architecture
The module uses four optical channels centered around 1295.56nm, 1300.05nm, 1304.58nm, and 1309.14nm. The channels are combined for transmission through the duplex LC optical interface.
QSFP28 and Duplex LC Interface
The QSFP28 form factor provides a compact and hot-pluggable interface for compatible 100Gbps networking equipment. The module uses a duplex LC connector for optical connectivity over single-mode fiber.
Digital Diagnostic Monitoring
The FTLC1156RDPL supports digital diagnostic functions through its management interface, allowing compatible host equipment to monitor supported optical operating parameters.
Technical Specifications
| Specification | Details |
| Brand | Finisar |
| Model | FTLC1156RDPL |
| Product Type | 100Gbps QSFP28 Optical Transceiver |
| Form Factor | QSFP28 |
| Optical Standard | 100GBASE-LR4 |
| Data Rate | 103.1Gbps |
| Maximum Distance | 10km |
| Fiber Type | Single-Mode Fiber (SMF) |
| Wavelength | 1310nm Band |
| Wavelength Channels | 1295.56nm, 1300.05nm, 1304.58nm, 1309.14nm |
| Optical Architecture | 4 × 25Gbps LAN-WDM |
| Connector | Duplex LC |
| Transmitter | DFB Laser |
| Receiver | PIN |
| Power Consumption | < 3.5W |
| Operating Temperature | 0°C to 70°C |
Applications
- 100GBASE-LR4 Ethernet networks
- Data center interconnects
- Enterprise backbone networks
- High-speed switch-to-switch links
- Network aggregation
- 10km single-mode fiber connectivity
Compatibility
The Finisar FTLC1156RDPL is designed for compatible networking equipment supporting QSFP28 100GBASE-LR4 optical transceivers. Before installation, verify the host device's supported transceiver list, QSFP28 interface, firmware requirements, and optical link specifications.
The installed single-mode fiber infrastructure should also meet the requirements for a 10km optical link.
