Fortinet FortiGate 200E FG-200E Next-Generation Firewall
Fortinet FortiGate 200E (FG-200E) is an enterprise next-generation firewall designed to provide consolidated network security, secure connectivity and traffic-control capabilities for business networks. It combines firewall protection with intrusion prevention, application control, VPN, secure networking and Fortinet Security Fabric integration in a 1RU rackmount platform.
The FortiGate 200E is built around Fortinet's security processing architecture and uses NP6Lite and CP9 hardware acceleration to improve the processing of networking and security workloads. Its interface design provides a practical combination of copper Gigabit Ethernet and fiber-based Gigabit SFP connectivity for enterprise WAN, LAN and security-edge deployments.
Technical Specifications
| Brand |
Fortinet |
| Product |
FortiGate 200E |
| Model |
FG-200E |
| Product Type |
Next-Generation Firewall (NGFW) |
| GE RJ45 WAN Interfaces |
2 |
| GE RJ45 Management / HA Ports |
2, including 1 management port and 1 HA port |
| GE RJ45 Switch Ports |
14 |
| Total GE RJ45 Interfaces |
18 |
| GE SFP Slots |
4 |
| Firewall Throughput |
Up to 20 Gbps, depending on packet size |
| Firewall Throughput - 64 Byte UDP |
Up to 9 Gbps |
| IPS Throughput |
Up to 2.2 Gbps |
| NGFW Throughput |
Up to 1.8 Gbps |
| Threat Protection Throughput |
Up to 1.2 Gbps |
| IPsec VPN Throughput |
Up to 7.2 Gbps |
| SSL-VPN Throughput |
Up to 900 Mbps |
| SSL Inspection Throughput |
Up to 820 Mbps |
| Application Control Throughput |
Up to 3.5 Gbps |
| Concurrent TCP Sessions |
Up to 2 million |
| New TCP Sessions/Second |
Up to 135,000 |
| IPsec VPN Tunnels |
Up to 2,000 gateway-to-gateway tunnels |
| Virtual Domains |
10 default / 25 maximum |
| Hardware Acceleration |
SPU NP6Lite and CP9 |
| USB |
1x USB port |
| Console |
1x RJ45 console |
| Form Factor |
1RU rackmount |
| Dimensions |
44.45 x 432 x 301 mm |
| Power Input |
100–240V AC, 50–60Hz |
| Operating Temperature |
0°C to 40°C |
Enterprise Network Security
The FortiGate 200E provides a consolidated security platform for controlling and protecting enterprise network traffic. It supports firewall policies, intrusion prevention, application control, secure VPN connectivity and other FortiOS-based security functions. This makes it suitable for organizations that want to combine security enforcement and network connectivity at the network edge.
Fortinet's Security Fabric architecture allows FortiGate appliances to work with other compatible Fortinet security and networking products. FortiGuard services can further extend security capabilities with threat intelligence and additional protection services, subject to the applicable subscription and licensing package.
Flexible Copper and Fiber Connectivity
The FG-200E provides 18x GE RJ45 interfaces, consisting of 2 WAN ports, 1 management port, 1 HA port and 14 switch ports. It also includes 4x GE SFP slots for compatible fiber or SFP-based network connections.
This interface combination makes the FortiGate 200E suitable for enterprise WAN gateways, branch aggregation, campus security, network segmentation and deployments where both copper Ethernet and fiber connectivity are required.
Hardware-Accelerated Performance
The FG-200E uses Fortinet's NP6Lite and CP9 security processing technologies to accelerate networking and security functions. Fortinet rates the platform for up to 20 Gbps firewall throughput, 2.2 Gbps IPS throughput, 1.8 Gbps NGFW throughput and 1.2 Gbps threat protection throughput under the specified test conditions.
Actual performance depends on traffic characteristics, enabled security features, packet sizes, inspection configuration and system conditions. Fortinet's published performance figures should therefore be treated as maximum test results rather than guaranteed real-world throughput.
VPN and Secure WAN Applications
With up to 7.2 Gbps of published IPsec VPN throughput, the FortiGate 200E can support secure site-to-site connectivity and enterprise remote-access architectures. FortiOS also provides secure networking and SD-WAN capabilities for organizations managing multiple WAN links, branches and distributed network environments.
High Availability and Rack Deployment
The 1RU form factor allows the FG-200E to be installed in standard enterprise network racks. Fortinet supports active-active and active-passive high-availability configurations, allowing organizations to design redundant firewall architectures for improved service continuity.
The platform supports 100–240V AC power input and is designed for controlled enterprise network environments with an operating temperature range of 0°C to 40°C.
Compatibility and Configuration Considerations
Before purchasing, verify the required FortiOS version, FortiGuard security services, FortiCare support package, SFP transceiver requirements and HA configuration. The 4 GE SFP slots should be matched with compatible Fortinet-supported transceivers and the appropriate fiber or copper media.
The FortiGate 200E should also be distinguished from the FortiGate 201E. Both models have the same primary interface configuration, while the 201E adds a 480GB onboard SSD. Confirm the exact SKU before purchasing when internal storage is required.
Typical Applications
- Enterprise next-generation firewall deployment
- Secure WAN and Internet gateway protection
- Branch and campus network security
- Site-to-site IPsec VPN connectivity
- Enterprise network segmentation
- Secure SD-WAN deployments
- Fortinet Security Fabric integration
- High-availability firewall architectures
FortiGate 200E Price in Bangladesh
For the latest Fortinet FortiGate 200E FG-200E price in Bangladesh, contact Datacom Technologies (BD). Pricing and availability may vary depending on sourcing, product condition, warranty, licensing and stock status.
Datacom Technologies (BD) can provide purchasing assistance and availability information for Fortinet network security products. For inquiries, contact sales@datacom.com.bd.
Important: FortiGate hardware and FortiCare/FortiGuard subscriptions may be quoted separately depending on the required deployment package. Confirm the hardware SKU, support term and security-service requirements before purchase.
