Fortinet FG-CABLE-SR10-SFP+5 100GE SR10 5m Fan-Out Breakout Cable
The Fortinet FG-CABLE-SR10-SFP+5 is a 5-meter 100GE SR10 parallel breakout fan-out cable designed to connect compatible 100Gbps CFP2 or QSFP28 interfaces to multiple 10Gbps network interfaces. According to Fortinet's transceiver documentation, the cable uses an MPO-to-10×LC configuration and is designed for parallel multimode fiber connectivity.
This cable provides a practical solution for network environments where a single 100GE connection needs to be broken out into 10 individual 10GE connections. The cable is specified with an OM3 multimode fiber construction and a 5-meter reach.
100GE SR10 Parallel Breakout Connectivity
The FG-CABLE-SR10-SFP+5 is designed for 100GE SR10 applications using parallel optical fiber. It provides a breakout connection from a compatible 100Gbps CFP2/QSFP28 interface to ten separate 10Gbps LC optical connections.
This architecture can simplify high-density network deployments where multiple 10Gbps links need to be connected to a single 100Gbps-capable optical interface.
5m MPO to 10×LC Fan-Out Cable
The cable has a 5-meter reach and uses an MPO connection on the 100GE side with 10 LC connectors on the breakout side. This allows a single parallel-fiber connection to be distributed across ten individual 10Gbps optical links.
OM3 Multimode Fiber
Fortinet specifies OM3 multimode fiber (MMF) for this cable. The multimode fiber construction is intended for short-range, high-density optical networking applications such as data centers and enterprise network infrastructure.
10× 10GE Fan-Out Architecture
The breakout design converts the parallel optical connection into 10 separate 10GE links. This makes the cable useful for connecting a high-speed aggregation interface to multiple lower-speed network interfaces.
Transceivers Not Included
The FG-CABLE-SR10-SFP+5 is a cable assembly rather than a complete transceiver module. Fortinet specifies that the required transceiver modules are not included, so compatible optical modules must be installed separately at the equipment interfaces.
Technical Specifications
| Specification |
Details |
| Brand |
Fortinet |
| Model |
FG-CABLE-SR10-SFP+5 |
| Product Type |
100GE SR10 Fan-Out / Parallel Breakout Cable |
| Overall Data Rate |
100Gbps |
| Breakout Configuration |
100GE to 10 × 10GE |
| Cable Length |
5m |
| Connector Configuration |
MPO to 10 × LC |
| Fiber Type |
OM3 Multimode Fiber (MMF) |
| Optical Architecture |
Parallel Fiber |
| Transceivers Included |
No |
Applications
- 100GE to 10GE network breakout
- Data center aggregation
- 100Gbps switch-to-10Gbps device connectivity
- High-density enterprise networks
- Parallel multimode fiber deployments
- Network migration and aggregation applications
Compatibility
The Fortinet FG-CABLE-SR10-SFP+5 is designed for compatible 100GE CFP2/QSFP28 parallel optical interfaces and 10GE LC-based optical connections. Fortinet identifies the cable as a 100 GE CFP2/QSFP28 parallel breakout MPO to 10×LC cable.
Before deployment, verify the connected equipment's supported transceiver types, optical standards, fiber requirements, port configuration, and breakout capabilities. The appropriate compatible transceiver modules must be purchased separately.
Buy Fortinet FG-CABLE-SR10-SFP+5 in Bangladesh
Datacom Technologies (BD) supplies Fortinet networking cables, optical transceivers, fiber connectivity products, and data center networking solutions in Bangladesh. The FG-CABLE-SR10-SFP+5 is suitable for 100GE-to-10GE breakout applications requiring a 5-meter OM3 multimode fiber connection.
For enterprise, ISP, telecom, data center, and project requirements, customers can request a quotation based on the required breakout configuration, cable length, optical modules, fiber type, and host equipment.
