About Fujitsu 10601834165 300GB 15K SAS 12Gbps 2.5" SFF Hot-Plug Server HDD in Bangladesh
The Fujitsu 10601834165 is a 300GB enterprise SAS hard drive designed for compatible Fujitsu server and storage environments. Featuring a 15,000 RPM rotational speed, SAS 12Gbps interface, 2.5-inch Small Form Factor design and 512n sector format, it provides high-speed enterprise storage for servers, RAID arrays, transactional workloads and other performance-oriented applications.
The 10601834165 is associated with Fujitsu part numbers A3C40178586 and S26361-F5531-L530, and is also associated with the HUC156030CSS204 drive platform. Enterprise hardware listings identify the configuration as a 300GB, 15K RPM, SAS 12Gbps, 2.5-inch SFF enterprise HDD with hot-plug support. ([servershop24.com](https://www.servershop24.de/en/fujitsu-300gb-12g-15k-sas-disk/a-125870/))
Fujitsu 10601834165 300GB SAS HDD Specifications & Features
| Specification | Details |
|---|
| Brand | Fujitsu |
| Part Number | 10601834165 |
| Related Part Number | A3C40178586 |
| Fujitsu P/N | S26361-F5531-L530 |
| Associated Drive Model | HUC156030CSS204 |
| Capacity | 300GB |
| Rotational Speed | 15,000 RPM |
| Interface | SAS 12Gbps |
| Form Factor | 2.5-inch SFF |
| Sector Format | 512n |
| Cache | 128MB |
| Recording Technology | CMR |
| Drive Class | Enterprise |
| Hot-Plug | Yes |
Overview
The Fujitsu 10601834165 provides 300GB of enterprise storage using a high-speed 15,000 RPM SAS platform. Its SAS 12Gbps interface and 2.5-inch SFF form factor make it suitable for server environments where fast disk access, enterprise reliability and compact drive density are important.
The drive is designed for compatible Fujitsu server and storage configurations and is commonly supplied with a suitable hot-plug carrier. Current enterprise listings identify it for Fujitsu PRIMERGY systems and compatible M-Series storage configurations.
Buy Fujitsu 10601834165 300GB 15K SAS HDD in Bangladesh
Purchase the Fujitsu 10601834165 300GB 15,000 RPM SAS 12Gbps 2.5-inch SFF Hot-Plug Server Hard Drive from Datacom Technologies (BD). We supply enterprise server HDDs, SAS/SATA storage, RAID components and data center hardware in Bangladesh with competitive pricing, technical consultation and nationwide delivery.
Key Features
- 300GB enterprise storage capacity
- 15,000 RPM rotational speed
- SAS 12Gbps interface
- 2.5-inch SFF form factor
- 512n native sector format
- 128MB cache
- CMR recording technology
- Hot-Plug capability
- Enterprise-class server HDD
- Suitable for compatible Fujitsu PRIMERGY systems
- Suitable for supported SAS RAID configurations
- Designed for performance-oriented server workloads
Applications
- Fujitsu PRIMERGY Servers
- Enterprise Database Servers
- Transactional Applications
- Server RAID Arrays
- Virtualization Storage
- Enterprise File Servers
- Business Application Servers
- High-IOPS HDD Storage
- Data Center Infrastructure
- Performance-Oriented Storage Tiers
300GB Enterprise Storage
The 300GB capacity is designed for enterprise server environments where fast-access storage is prioritized over maximum storage density.
Multiple 10601834165 drives can be combined in supported RAID configurations to create redundant storage arrays and improve storage availability. Actual usable capacity depends on the RAID level, number of drives, filesystem and controller overhead.
15,000 RPM Performance
The 15,000 RPM rotational speed provides faster mechanical response than typical 7,200 RPM enterprise HDDs. This makes the drive suitable for workloads involving frequent random access and higher I/O activity.
Typical applications include transactional databases, business applications, enterprise server workloads and RAID storage where HDD-based performance is required.
SAS 12Gbps Interface
The 10601834165 uses a SAS 12Gbps interface. Enterprise listings specify a 12Gbps SAS data-transfer interface for this 300GB 15K configuration. ([servershop24.com](https://www.servershop24.de/en/fujitsu-300gb-12g-15k-sas-disk/a-125870/))
SAS provides enterprise-oriented connectivity and is designed for use with compatible SAS controllers, server backplanes and storage systems. The 12Gbps figure represents the theoretical interface link rate; actual HDD performance depends on the mechanical drive, workload, controller and storage configuration.
2.5-Inch SFF Form Factor
The Fujitsu 10601834165 uses a 2.5-inch Small Form Factor design with a 15mm drive height. This compact form factor enables higher drive density in compatible server chassis.
The SFF configuration is particularly useful in Fujitsu PRIMERGY systems and other enterprise servers designed for 2.5-inch hot-plug storage bays.
512n Native Sector Format
The 10601834165 configuration is documented with a 512n native sector format. Enterprise listings identify the drive as using 512-byte native sectors. ([servershop24.com](https://www.servershop24.de/en/fujitsu-300gb-12g-15k-sas-disk/a-125870/))
When installing the drive into an existing RAID array, verify sector-format compatibility with the storage controller, operating system, firmware and other installed drives.
128MB Cache
The documented 10601834165 configuration is listed with 128MB cache. ([servershop24.com](https://www.servershop24.de/en/fujitsu-300gb-12g-15k-sas-disk/a-125870/))
The cache provides temporary buffering for read and write operations and complements the drive's 15,000 RPM mechanical performance.
CMR Recording Technology
The 10601834165 configuration is documented with CMR recording technology. CMR is well suited to enterprise environments where predictable HDD write behavior is important.
Hot-Plug Design
The Fujitsu 10601834165 is designed for hot-plug server storage configurations. Enterprise listings identify the drive as hot-plug capable and show it with a compatible Fujitsu carrier. ([servershop24.com](https://www.servershop24.de/en/fujitsu-300gb-12g-15k-sas-disk/a-125870/))
In a compatible server, hot-plug functionality allows supported drives to be serviced or replaced without powering down the complete system, provided that the server backplane, controller, RAID configuration and operating system support the operation.
Enterprise SAS Storage
The 10601834165 is an enterprise-class SAS HDD rather than a consumer SATA drive. SAS connectivity makes it suitable for enterprise server environments equipped with compatible SAS controllers and backplanes.
The combination of 15,000 RPM operation and SAS 12Gbps connectivity makes this drive particularly appropriate for performance-oriented HDD storage tiers.
Fujitsu PRIMERGY Compatibility
Enterprise listings identify the 10601834165 / A3C40178586 configuration for numerous Fujitsu PRIMERGY systems, including BX2560, RX1330, RX2520, RX2530, RX2540, RX2560, RX4770, TX1320, TX1330, TX2550 and TX2560 series configurations. ([servershop24.com](https://www.servershop24.de/en/fujitsu-300gb-12g-15k-sas-disk/a-125870/))
Another enterprise listing specifically identifies the related S26361-F5531-L530 configuration for Fujitsu PRIMERGY BX2560, RX1330, RX2520, RX2530, RX2540, RX2560, RX4770, TX1320, TX1330, TX2550 and TX2560 systems. ([topserverparts.com](https://www.topserverparts.com/en/Fujitsu-Primergy-300GB-12G-15k-25-Hard-Drive-S26361-F5531-L530))
Compatibility can vary by server generation, storage controller, backplane and firmware, so the exact Fujitsu server configuration should be checked before installation.
Fujitsu ETERNUS JX40 S2 Compatibility
The related A3C40178586 configuration is also documented for the Fujitsu ETERNUS JX40 S2 platform. Enterprise hardware references identify the drive as a 300GB 15K SAS 12G 2.5-inch drive with Fujitsu ETERNUS JX40 S2 compatibility. ([gekko-computer.de](https://www.gekko-computer.de/en/p/Fujitsu-SAS-hard-drive-300GB-15k-SAS-12G-SFF-JX40-S2-A3C40178586))
RAID Storage
The Fujitsu 10601834165 can be used in supported SAS RAID configurations. Multiple 300GB drives can be combined to provide redundancy, improved availability and larger storage pools.
Supported RAID levels depend on the installed SAS RAID controller and server configuration. RAID improves availability against certain drive failures but should always be combined with an independent backup strategy.
Performance-Oriented Storage
The 10601834165 is best positioned as a performance-oriented enterprise HDD. Its 15,000 RPM spindle speed provides faster mechanical access characteristics than typical 7,200 RPM HDDs.
It is suitable for workloads such as transactional applications, databases, business applications and other server workloads where HDD-based random-access performance is important.
Fujitsu 10601834165 vs 300GB 10K SAS HDD
| Feature |
Fujitsu 10601834165 |
Typical 300GB 10K SAS HDD |
| Capacity |
300GB |
300GB |
| Rotational Speed |
15,000 RPM |
10,000 RPM |
| Interface |
SAS 12Gbps |
SAS 6Gbps / 12Gbps |
| Sector Format |
512n |
Model dependent |
| Form Factor |
2.5-inch SFF |
2.5-inch SFF |
| Primary Focus |
Performance-oriented HDD storage |
General enterprise HDD storage |
Compatibility Considerations
The 10601834165 is a SAS drive and requires a compatible SAS controller and backplane. It should not be treated as a direct SATA replacement.
- Compatible 2.5-inch SFF bay
- Compatible SAS backplane
- Compatible SAS RAID/HBA controller
- Support for 512n sectors
- Compatible server firmware
- Appropriate Fujitsu hot-plug carrier
When replacing an existing drive in a RAID array, carefully match capacity, interface, sector format, form factor and controller compatibility.
Benefits
- 300GB enterprise storage capacity
- 15,000 RPM performance
- SAS 12Gbps connectivity
- 2.5-inch SFF form factor
- 512n native sector format
- 128MB cache
- CMR recording technology
- Hot-Plug capability
- Suitable for Fujitsu PRIMERGY environments
- Suitable for supported SAS RAID configurations
- Ideal for performance-oriented server workloads
Why Buy from Datacom Technologies (BD)?
Datacom Technologies (BD) supplies enterprise server hard drives, Fujitsu storage components, SAS/SATA HDDs, RAID controllers and data center hardware in Bangladesh. Customers can receive competitive pricing, technical consultation, deployment assistance and nationwide delivery.
- Call/WhatsApp: +8801748173213
- Email: sales@datacom.com.bd
- Alternative Email: datacomtechnologiesbd@gmail.com
- Office: Tropical Center, 218, Dr. Kudroti Khuda Road, New Elephant Road, Dhaka-1205, Bangladesh
Frequently Asked Questions (FAQ)
Q1: What is the Fujitsu 10601834165?
The Fujitsu 10601834165 is a 300GB 15,000 RPM SAS 12Gbps 2.5-inch SFF enterprise hot-plug hard drive.
Q2: What is the storage capacity?
The drive provides 300GB of nominal storage capacity.
Q3: What is the rotational speed?
The drive operates at 15,000 RPM.
Q4: What interface does 10601834165 use?
It uses a SAS 12Gbps interface.
Q5: What sector format does 10601834165 use?
The documented configuration uses a 512n native sector format. ([servershop24.com](https://www.servershop24.de/en/fujitsu-300gb-12g-15k-sas-disk/a-125870/))
Q6: What is the form factor?
The drive uses a 2.5-inch Small Form Factor with a 15mm drive height.
Q7: Is 10601834165 hot-pluggable?
Yes. The documented configuration is hot-plug capable and can be supplied with a compatible Fujitsu carrier. ([servershop24.com](https://www.servershop24.de/en/fujitsu-300gb-12g-15k-sas-disk/a-125870/))
Q8: How much cache does the drive have?
The documented configuration has 128MB cache. ([servershop24.com](https://www.servershop24.de/en/fujitsu-300gb-12g-15k-sas-disk/a-125870/))
Q9: What are the related part numbers?
10601834165 is associated with A3C40178586 and S26361-F5531-L530. It is also associated with HUC156030CSS204. ([topserverparts.com](https://www.topserverparts.com/en/Fujitsu-Primergy-300GB-12G-15k-25-Hard-Drive-S26361-F5531-L530))
Q10: Is 10601834165 a SATA drive?
No. It is a SAS 12Gbps enterprise hard drive.
Q11: Can 10601834165 be used in RAID?
Yes, when supported by the installed SAS RAID controller, backplane and server configuration.
Q12: Which Fujitsu servers support this drive?
Documented compatible systems include various Fujitsu PRIMERGY BX, RX and TX series systems. Exact compatibility depends on the server generation, backplane and controller. ([servershop24.com](https://www.servershop24.de/en/fujitsu-300gb-12g-15k-sas-disk/a-125870/))
Q13: Is it suitable for databases?
Its 15,000 RPM spindle speed and SAS 12Gbps interface make it suitable for performance-oriented enterprise workloads, including certain database and transactional applications.
Q14: Is the drive 512e?
No. The documented configuration is 512n, meaning 512-byte native sectors.
Q15: Where can I buy Fujitsu 10601834165 in Bangladesh?
You can contact Datacom Technologies (BD) for Fujitsu server HDDs, SAS/SATA storage, RAID components and enterprise data center hardware with competitive pricing and nationwide delivery.
