Grandstream GWN7803P 24-Port Gigabit PoE+ Managed Switch

The Grandstream GWN7803P is a Layer 2+ managed Gigabit Ethernet switch designed for business networks that require centralized management, PoE connectivity, network segmentation and flexible uplink options. It provides 24 Gigabit Ethernet ports with IEEE 802.3af/at PoE+ support and 4 Gigabit SFP ports for fiber-based uplinks.

With a 56Gbps switching capacity, 41.66 Mpps forwarding rate and up to 360W total PoE output, the GWN7803P can connect and power compatible IP phones, IP cameras, wireless access points and other PoE-enabled network devices from a single managed switch.

Grandstream GWN7803P Technical Features

• Layer 2+ managed Gigabit Ethernet switch
• 24 × 10/100/1000Mbps RJ45 Ethernet ports
• 24 × PoE ports supporting IEEE 802.3af/at
• Up to 30W PoE output per port
• 360W maximum total PoE output power
• 4 × 1000Mbps SFP ports for fiber uplinks
• 56Gbps switching capacity
• 41.66 Mpps forwarding rate
• 28Gbps total non-blocking throughput
• 4.1MB packet buffer
• 8K static, dynamic and filtering MAC addresses
• Support for up to 4K VLANs
• 8 link aggregation groups
• Spanning Tree with up to 16 MSTP instances
• IGMP Snooping and MLD Snooping
• QoS, traffic shaping, rate limiting and ACL features
• 1.5K ACL capacity for Ethernet, IPv4 and IPv6
• SNMP, RMON, LLDP and LLDP-MED management features
• Store-and-forward switching

Detailed Specifications

Compatibility

The GWN7803P is designed for Ethernet devices supporting standard network connectivity and compatible IEEE 802.3af/at PoE requirements. Its PoE ports can be used with compatible IP phones, IP cameras, Wi-Fi access points and other PoE-powered endpoints. Fiber uplink compatibility depends on the SFP module, fiber type, wavelength, reach and equipment at the remote end, so the specific SFP module should be selected according to the network design.

PoE availability also depends on the connected device's power requirements and the switch's available PoE budget. The maximum advertised PoE output is 30W per port and 360W in total; actual deployment capacity depends on the connected devices and overall power demand.

Applications and Use Cases

• Small and medium business network infrastructure
• Enterprise access-layer networking
• IP surveillance and PoE camera deployments
• IP telephone and unified communications networks
• Wireless access point deployments
• Office and branch network connectivity
• VLAN-based network segmentation
• Fiber uplink and network aggregation applications
• IoT and other Ethernet-connected PoE deployments

Why Choose Grandstream GWN7803P?

The GWN7803P combines 24 Gigabit PoE+ access ports with four Gigabit SFP uplinks in a rack-mountable Layer 2+ managed switch. Its 360W PoE budget, VLAN capabilities, QoS controls, ACL support, link aggregation and centralized management options make it suitable for organizations building structured wired networks with PoE-powered endpoints.

Grandstream GWN7803P Price in Bangladesh

For the latest Grandstream GWN7803P price in Bangladesh, contact Datacom Technologies (BD). Pricing and availability may vary depending on sourcing, product condition, warranty and stock status.
