H3C CFP2-100G-LR4-WDM1300 100Gbps 10km Transceiver Module
The H3C CFP2-100G-LR4-WDM1300 is a 100Gbps CFP2 optical transceiver designed for long-distance Ethernet connectivity over single-mode fiber. It uses a four-lane WDM optical architecture and provides a transmission distance of up to 10km over compatible 9/125µm single-mode fiber.
The module uses a dual LC optical interface and operates across four optical wavelengths: 1295.56nm, 1300.05nm, 1304.58nm, and 1309.14nm. This wavelength-division multiplexing design allows the four optical lanes to operate over a single pair of single-mode fiber connections.
H3C CFP2-100G-LR4-WDM1300 Optical Connectivity
The CFP2-100G-LR4-WDM1300 is designed for 100Gbps network connections where a longer optical reach is required. Its LR4 architecture supports up to 10km transmission, making it suitable for connections between network locations, aggregation equipment, data center infrastructure, and other compatible 100Gbps endpoints.
The module uses four WDM optical channels, each operating at a different wavelength within the 1300nm wavelength range. The four lanes are multiplexed for transmission through the dual LC single-mode fiber interface.
10km Single-Mode Fiber Transmission
The transceiver is designed for 9/125µm single-mode fiber and supports a maximum transmission distance of 10km. The actual link distance depends on the fiber infrastructure, connector quality, optical loss, and the optical characteristics of the connected equipment.
Four-Lane WDM Architecture
The CFP2-100G-LR4-WDM1300 uses four optical lanes at 1295.56nm, 1300.05nm, 1304.58nm, and 1309.14nm. WDM technology allows these optical channels to share the same fiber pair while maintaining separate wavelength channels for the 100Gbps connection.
Dual LC Optical Interface
The module uses two LC optical connectors for the fiber connection. The dual-LC interface provides separate transmit and receive paths over a compatible single-mode fiber pair.
CFP2 Form Factor
The CFP2 form factor provides a high-density 100Gbps optical interface for compatible networking equipment. The module is designed for H3C platforms that support the CFP2-100G-LR4-WDM1300 transceiver.
Technical Specifications
| Specification | Details |
| Brand | H3C |
| Model | CFP2-100G-LR4-WDM1300 |
| Product Type | 100Gbps CFP2 Optical Transceiver |
| Form Factor | CFP2 |
| Transmission Rate | 100Gbps |
| Optical Type | LR4 / WDM |
| Wavelengths | 1295.56nm, 1300.05nm, 1304.58nm, 1309.14nm |
| Fiber Type | Single-Mode Fiber (SMF) |
| Fiber Diameter | 9/125µm |
| Maximum Distance | 10km |
| Connector | Dual LC |
| Average Transmit Power | -4.3 to +4.5 dBm |
| Average Receive Power | -10.6 to +4.5 dBm |
Applications
- 100GbE network connectivity
- Data center interconnects
- Enterprise network backbone links
- Network aggregation
- Core network connectivity
- Long-distance single-mode fiber links
Compatibility
The H3C CFP2-100G-LR4-WDM1300 is designed for compatible H3C networking equipment supporting CFP2 optical transceiver modules. H3C documentation identifies this model as a 100Gbps CFP2 module using a dual-LC interface and supporting up to 10km over 9/125µm single-mode fiber. :contentReference[oaicite:0]{index=0}
Before installation, verify the exact H3C device, CFP2 interface, supported transceiver list, fiber type, and optical link requirements.
Buy H3C CFP2-100G-LR4-WDM1300 in Bangladesh
Datacom Technologies (BD) supplies H3C optical transceivers, enterprise networking equipment, fiber connectivity products, and data center hardware in Bangladesh. The H3C CFP2-100G-LR4-WDM1300 is suitable for compatible 100Gbps networking environments requiring 10km single-mode fiber connectivity.
For corporate and project requirements, customers can contact Datacom Technologies (BD) for product selection assistance, technical consultation, and professional networking equipment supply.
