Huawei 40GBASE QSFP+ 10km LC DOM Transceiver Module
Datacom Technologies BD is your trusted partner for all your networking equipment needs. We offer a wide range of products, including the Huawei 40GBASE QSFP+ 10km LC DOM Transceiver Module. With our competitive prices, fast delivery, and excellent customer support, you can confidently purchase this high-quality transceiver module from us.
Huawei 40GBASE QSFP+ 10km Module Specification:
| Parameter |
Value |
| Form Factor |
QSFP+ |
| Data Rate |
40 Gbps |
| Wavelength |
1310 nm |
| Distance |
10 km |
| Connector Type |
LC |
| Fiber Type |
Single-mode (SMF) |
| Transmitter Type |
DFB |
| Receiver Type |
PIN |
| TX Power |
-7 dBm to 2.3 dBm |
| RX Sensitivity |
-11.5 dBm |
| Overload Power |
2.3 dBm |
| Extinction Ratio |
3.5 dB |
| Operating Temperature |
0°C to 70°C |
| Digital Diagnostics Monitoring (DDM) |
Supported |
Description
The
Huawei 40GBASE QSFP+ 10km LC DOM Transceiver Module is a high-performance optical transceiver designed for long-distance, high-bandwidth data transmission over single-mode fiber (SMF). It offers a data rate of 40 Gbps, enabling efficient and reliable network connectivity across various applications.
This module utilizes Quad Small Form-factor Pluggable (QSFP+) technology, which allows four separate 10 Gbps channels to be multiplexed onto a single fiber. This enables a significant increase in data transmission capacity compared to traditional single-mode transceivers.
The 40GBASE QSFP+ module is equipped with LC connectors, which are widely used in optical networking due to their small size, high density, and ease of use. The 1310 nm wavelength is ideal for long-distance transmission over single-mode fiber, as it minimizes signal attenuation and dispersion.
The module's internal components include a Distributed Feedback Laser (DFB) transmitter and a PIN photodiode receiver. These components are optimized for high-speed, long-distance transmission, ensuring reliable and error-free data transfer.
The module also supports Digital Diagnostics Monitoring (DDM), which provides real-time monitoring of key operating parameters such as temperature, voltage, bias current, and optical power. This allows network administrators to proactively identify and address potential issues before they impact network performance.
Supported/Comparable Models
The Huawei 40GBASE QSFP+ 10km LC DOM SFP is compatible with a wide range of Huawei networking equipment, including switches, routers, and optical transport systems. It is also compatible with other vendor's equipment that supports the 40GBASE-LR4 standard.
Some comparable models from other vendors include:
Cisco SFP-40G-LR4
Juniper QSFP-40G-LR4
Finisar QSFP-40G-LR4
Brocade QSFP-40G-LR4
What is the price of a Huawei 40GBASE QSFP+ 10km LC DOM Transceiver Module in Bangladesh?
The Huawei 40GBASE QSFP+ 10km LC DOM SFP typically ranges in price from TK30,000/= to TK50,000/= in Bangladesh. However, please note that actual pricing may vary due to factors such as quantity, warranty, and current market conditions.
For a quote, contact
Datacom Technologies BD:
Call/WhatsApp: +8801748173213
Email: sales@datacomtechbd.com or datacomtechnologiesbd@gmail.com
