About IBM 81Y1668 Brocade 1860 16Gb 1-Port FC HBA Card in Bangladesh
The IBM 81Y1668 Brocade 1860 16Gb 1-Port FC HBA Card is an enterprise-class Fibre Channel Host Bus Adapter designed to provide reliable and high-performance SAN connectivity for IBM System x servers. Built on Brocade Gen 5 Fibre Channel technology, this adapter delivers outstanding throughput, low latency, and enterprise-class reliability for virtualization, enterprise databases, cloud computing, and mission-critical storage environments.
Featuring a single 16Gb Fibre Channel port with a PCI Express 2.0 x8 interface, the adapter enables high-speed communication between servers and Fibre Channel Storage Area Networks (SANs). It supports automatic speed negotiation with 16Gb, 8Gb, 4Gb, and 2Gb Fibre Channel infrastructures, providing excellent investment protection while simplifying future storage upgrades.
The adapter supports advanced enterprise technologies including Boot from SAN, Fabric Assigned World Wide Name (FA-WWN), Brocade Server Application Optimization (SAO), Brocade Diagnostic Port (D-Port), NPIV, Quality of Service (QoS), End-to-End CRC protection, and centralized Brocade Host Connectivity Manager. These features improve SAN availability, simplify administration, and maximize storage efficiency.
Whether deploying virtualization, expanding Fibre Channel infrastructure, or upgrading enterprise storage networking, the IBM 81Y1668 Brocade 1860 FC HBA delivers dependable performance, enterprise-grade reliability, and scalable SAN connectivity.
Buy IBM 81Y1668 Brocade 1860 16Gb 1-Port FC HBA Card in Bangladesh
Looking for the original IBM 81Y1668 Brocade 1860 16Gb 1-Port FC HBA Card in Bangladesh? Datacom Technologies (BD) supplies genuine IBM enterprise servers, storage systems, networking equipment, and Fibre Channel adapters with competitive pricing, expert consultation, and dependable after-sales support. We provide authentic enterprise hardware with fast nationwide delivery.
Compatibility
- IBM System x Servers
- IBM BladeCenter Servers
- PCI Express 2.0 x8 Compatible Enterprise Servers
- 16Gb / 8Gb / 4Gb / 2Gb Fibre Channel SAN Infrastructure
- IBM Storwize Storage Systems
- IBM FlashSystem Storage
- IBM SAN Switches
- VMware ESXi
- Microsoft Windows Server
- Red Hat Enterprise Linux
- SUSE Linux Enterprise Server
IBM 81Y1668 Brocade 1860 Specifications & Overview
| Specification |
Details |
| Product Type | Fibre Channel Host Bus Adapter |
| Product Name | IBM 81Y1668 Brocade 1860 16Gb 1-Port FC HBA Card |
| Brand | IBM |
| Part Number | 81Y1668 |
| Model | Brocade 1860 |
| Port Configuration | Single Port |
| Port Speed | 16Gb Fibre Channel |
| Bus Interface | PCI Express 2.0 x8 |
| Connector Type | 1 × LC SFP+ Fibre Channel Port |
| Supported FC Speeds | 16Gb / 8Gb / 4Gb / 2Gb Auto Negotiation |
| Performance | Over 500,000 IOPS per Port |
| Supported Features | Boot from SAN, FA-WWN, SAO, D-Port Diagnostics, NPIV, QoS, End-to-End CRC |
| Management | Brocade Host Connectivity Manager (HCM) |
| Form Factor | Low Profile PCI Express Adapter |
Applications
- Enterprise Storage Area Networks (SAN)
- Server Virtualization
- Enterprise Database Servers
- Cloud Computing
- Backup & Disaster Recovery
- IBM FlashSystem Storage
- IBM Storwize Storage
- Business-Critical Applications
- Enterprise Data Centers
- Storage Consolidation
Benefits of Choosing This Product
The IBM 81Y1668 Brocade 1860 delivers enterprise-grade 16Gb Fibre Channel connectivity with low latency, excellent SAN performance, advanced diagnostics, and enterprise security features. It is an ideal solution for organizations requiring dependable Fibre Channel storage networking.
Why Buy from Datacom Technologies (BD)?
Datacom Technologies (BD) is a trusted supplier of enterprise servers, storage systems, networking equipment, and data center hardware in Bangladesh. We provide genuine IBM enterprise products, competitive pricing, expert technical consultation, and dependable after-sales support.
- Call/WhatsApp: +8801748173213
- Email: sales@datacom.com.bd
- Alternative Email: datacomtechnologiesbd@gmail.com
- Office: Tropical Center, 218, Dr. Kudroti Khuda Road, New Elephant Road, Dhaka-1205, Bangladesh.
Frequently Asked Questions (FAQ)
Q1: How many Fibre Channel ports are available?
The adapter features one 16Gb Fibre Channel port.
Q2: Does it support Boot from SAN?
Yes. Boot from SAN is fully supported.
Q3: Is it compatible with older Fibre Channel networks?
Yes. It supports 16Gb, 8Gb, 4Gb, and 2Gb Fibre Channel environments.
Q4: Which servers are compatible?
It supports IBM System x servers and other compatible PCIe enterprise servers.
Q5: What workloads is it designed for?
It is ideal for virtualization, enterprise databases, backup infrastructure, cloud computing, and SAN deployments.
