About Moxa TCF-142-RM for NRack System
The Moxa TCF-142-RM is a high-performance Industrial Ethernet Switch designed for N-Rack Systems. It offers robust features such as redundant power supplies, wide operating temperature range, and advanced security protocols to ensure reliable and secure network connectivity. This versatile switch is perfect for various industrial applications, including factory automation, transportation, and energy.
Datacom Technologies BD is the authorized distributor of
Moxa Industrial Converter in Bangladesh. We offer the best price and warranty on all Moxa products.
Moxa TCF-142-RM Specification
| Feature |
Description |
| Serial Interface |
RS-232, RS-422, RS-485 |
| Baud Rate |
50 bps to 921.6 kbps (supports non-standard baudrates) |
| Flow Control |
ADDC® (automatic data direction control) for RS-485 |
| Fiber Type |
Multi-mode or Single-mode |
| Distance |
Up to 5 km (multi-mode), up to 40 km (single-mode) |
| Connector |
SC or ST connector |
| Power Supply |
12 VDC |
| Power Consumption |
150 mA @ 12 V |
| Operating Temperature |
0 to 60°C |
| Storage Temperature |
-20 to 75°C |
| Humidity |
5 to 95% (non-condensing) |
| Dimensions |
86.8 x 136.5 x 21 mm |
| Weight |
105 g |
Moxa TCF-142-RM Description:
The Moxa
TCF-142-RM Series is a versatile solution for extending serial communication distances over fiber-optic cables. These slide-in modules are designed to seamlessly integrate into Moxa's TRC-190 chassis, providing a compact and reliable way to convert RS-232, RS-422, or RS-485 signals to fiber-optic signals.
The TCF-142-RM Series supports a wide range of baud rates and features automatic baud rate detection, eliminating the need for manual configuration. ADDC® technology enables automatic data direction control for RS-485, simplifying network setup and maintenance. With its rugged design and wide operating temperature range, the TCF-142-RM Series is well-suited for harsh industrial environments.
The TCF-142-RM Series offers a variety of models to meet different fiber-optic requirements. Multi-mode models are ideal for shorter distances, while single-mode models are suitable for longer distances. The SC and ST connectors provide flexibility in fiber cable connections.
Key Features:
Versatile Serial Interface: Supports RS-232, RS-422, and RS-485 signals.
Long-Distance Transmission: Extends serial communication up to 40 km with single-mode fiber or 5 km with multi-mode fiber.
Automatic Baudrate Detection: Eliminates the need for manual configuration, ensuring seamless operation.
ADDC® Technology: Enables automatic data direction control for RS-485, simplifying network setup and maintenance.
Rugged Design: Built for harsh industrial environments, with IP30 protection and a wide operating temperature range.
Easy Installation: Slide-in module design allows for quick and easy installation into the TRC-190 chassis.
Supported/Comparable Models:
Moxa TCF-142-M-SC-RM (Multi-mode SC connector)
TCF-142-M-ST-RM (Multi-mode ST connector)
TCF-142-S-SC-RM (Single-mode SC connector)
TCF-142-S-ST-RM (Single-mode ST connector)
What is the price of Moxa TCF-142-RM for NRack System in BD?
The Moxa TCF-142-RM for NRack System price in Bangladesh starts from
BDT-35,000/= to BDT-75,000/= Unit depending on model, capacity, features and warranty. To order your Moxa Industrial Converter , please contact us by call or WhatsApp (+8801748173213). You can also browse our online shop "
Datacom Technologies (BD)" and order your Moxa Industrial Converter directly.
Call/WhatsApp: +8801748173213
Email: sales@datacomtechbd.com or datacomtechnologiesbd@gmail.com
Explore other Moxa Industrial Converter here.
