Key Features
- Brand: NOYAFA
- Model: NF-8508
- Compliance: Industry network testing standards
- Display: Color LCD screen
NOYAFA NF-8508 Multifunction Network Cable Tester
The NOYAFA NF-8508 Network Cable Tester is a multifunctional handheld testing tool designed for network technicians, fiber optic installers and IT maintenance professionals. It combines copper network cable diagnostics, cable tracing, cable length measurement, PoE testing, an optical power meter (OPM) and a visual fault locator (VFL) in one device. This integrated design helps simplify troubleshooting across Ethernet cabling and compatible fiber optic networks.
Ethernet Cable Testing and Network Troubleshooting
The NF-8508 supports RJ45 network cable testing, wire mapping, continuity checks and identification of common wiring faults, including open and short circuits. Its cable tracing and port-flashing functions help technicians locate cable runs and identify connected network ports. The cable-length function supports measurements up to approximately 200 metres, depending on cable conditions and test requirements.
Integrated Optical Power Meter and Visual Fault Locator
The optical power meter measures received optical signal power at supported wavelengths, helping technicians assess fiber links during installation and maintenance. The integrated visual fault locator uses visible red laser light to help identify breaks, bends and other faults along compatible fiber optic cables. The listed optical power meter wavelength options are 850, 1300, 1310, 1490, 1550 and 1625 nm; confirm the exact measurement capability for the supplied version.
PoE Testing and Additional Functions
The tester supports PoE checks to help identify power delivery information on compatible Ethernet connections. Additional functions include cable tracing, RJ45 crimping-quality checks, non-contact voltage detection and an integrated illumination light. USB Type-C charging and a rechargeable lithium battery support portable field use.
Technical Specifications
| Specification | Details |
|---|---|
| Brand | NOYAFA |
| Model | NF-8508 |
| Product Type | Multifunction Network Cable Tester |
| Copper Cable Testing | RJ45 Ethernet cable testing, wire mapping and continuity diagnostics |
| Additional Cable Support | RJ11 and other supported cable types, depending on adapters and test mode |
| Cable Length Measurement | Up to approximately 200 m |
| Network Functions | Cable tracing, port flashing, PoE testing and crimping-quality checks |
| Optical Power Meter | Supports optical power measurement at specified wavelengths |
| OPM Wavelength Options | 850, 1300, 1310, 1490, 1550 and 1625 nm, subject to version specifications |
| Visual Fault Locator | Integrated visible red laser; listed output 10 mW |
| Additional Functions | Non-contact voltage detection and illumination light |
| Battery | Rechargeable 3.7 V lithium battery, listed capacity 1500 mAh |
| Charging Interface | USB Type-C |
Applications
- Ethernet cable installation and troubleshooting
- LAN and structured cabling maintenance
- Fiber optic link inspection and optical power checks
- Visual localization of fiber breaks and bends
- PoE network installation and troubleshooting
- Telecommunications, server rooms, data centers and CCTV network deployments
Compatibility and Safe Operation
Confirm connector types, fiber compatibility, wavelength support and included adapters before testing. Optical power readings depend on the fiber system and test wavelength. Never look directly into a fiber connector or the VFL output, and follow the manufacturer's safety instructions when working with optical equipment or live network cabling.
