Aruba AP-565 Wi-Fi 6 Outdoor Access Point – Dual 2x2 MIMO, 1.49 Gbps, Integrated Omni Antennas
The HPE Aruba Networking AP-565 is a rugged outdoor Wi-Fi 6 access point designed to provide reliable high-performance wireless connectivity in outdoor and challenging environmental conditions. It features concurrent 2.4 GHz and 5 GHz 802.11ax connectivity with dual 2x2 MIMO radios and integrated omnidirectional antennas.
The AP-565 delivers a peak aggregate data rate of up to 1.49 Gbps, with support for up to 1.2 Gbps on 5 GHz and 574 Mbps on 2.4 GHz under maximum Wi-Fi 6 conditions. Its hardened outdoor construction, IP66/IP67 protection and wide operating temperature range make it suitable for outdoor deployments and warehouse environments.
Aruba AP-565 Key Features
- Wi-Fi 6 (IEEE 802.11ax) outdoor access point
- Dual 2x2 MIMO radios supporting simultaneous 2.4 GHz and 5 GHz operation
- Up to 1.49 Gbps peak aggregate wireless data rate
- Integrated omnidirectional antennas
- Up to 1.2 Gbps on 5 GHz and 574 Mbps on 2.4 GHz
- OFDMA and bidirectional MU-MIMO for improved wireless efficiency
- Integrated Bluetooth 5 and Zigbee/802.15.4 IoT radio
- 1 x Gigabit Ethernet network interface
- IEEE 802.3af/at/bt and 802.3az PoE support
- IP66/IP67-rated outdoor hardened enclosure
- Designed for operation in all weather conditions
- Supports Aruba wireless operating systems and Instant deployments
Technical Specifications
| Specification | Details |
|---|
| Brand | HPE Aruba Networking |
| Model | AP-565 |
| Series | Aruba 560 Series |
| Product Type | Outdoor Hardened Access Point |
| Wireless Standard | IEEE 802.11ax (Wi-Fi 6) |
| Radio Configuration | Dual 2x2 MIMO |
| 2.4 GHz Radio | 2x2 MIMO, up to 574 Mbps maximum data rate |
| 5 GHz Radio | 2x2 MIMO, up to 1.2 Gbps maximum data rate |
| Peak Aggregate Data Rate | Up to 1.49 Gbps |
| 2.4 GHz Channel Width | 20/40 MHz |
| 5 GHz Channel Width | 20/40/80 MHz |
| Wi-Fi Antennas | Integrated omnidirectional antennas |
| 5 GHz Antenna Gain | Up to 5.4 dBi |
| 2.4 GHz Antenna Gain | Up to 3.2 dBi |
| Ethernet | 1 x 10/100/1000BASE-T Gigabit Ethernet |
| PoE | IEEE 802.3af/at/bt and 802.3az support |
| IoT Connectivity | Bluetooth 5 or IEEE 802.15.4/Zigbee |
| Location Services | 802.11 FTM support |
| USB | USB-C console interface |
| Environmental Protection | IP66/IP67 |
| Operating Temperature | -40°C to +55°C with full solar loading |
| Operating Humidity | 5% to 95% non-condensing |
| Operating Altitude | Up to 3,000 m |
| Wind Survival | Up to 165 mph |
| Salt Spray Resistance | Tested to ASTM B117-07A, 200 hours |
| Management | On-premises, public cloud, VPC and as-a-service options |
| Warranty | Limited lifetime warranty |
Outdoor Wi-Fi 6 Connectivity
The Aruba AP-565 provides concurrent 2.4 GHz and 5 GHz Wi-Fi 6 connectivity for outdoor and industrial wireless environments. Its dual 2x2 MIMO architecture and integrated omnidirectional antennas provide broad wireless coverage without requiring separate external Wi-Fi antennas.
Dual-Band 2x2 MIMO Performance
The 5 GHz radio supports up to 1.2 Gbps under maximum Wi-Fi 6 conditions, while the 2.4 GHz radio supports up to 574 Mbps. The combined peak data rate is up to 1.49 Gbps.
Wi-Fi 6 Efficiency
Wi-Fi 6 technologies including OFDMA and bidirectional MU-MIMO help improve spectrum efficiency and airtime utilization when multiple compatible wireless clients are connected. The AP-565 also supports 1024-QAM and other 802.11ax capabilities.
Rugged Outdoor Construction
The AP-565 is engineered for outdoor deployment and is rated IP66/IP67 for protection against dust and water ingress. It is designed to operate across a wide temperature range from -40°C to +55°C with full solar loading and is rated for operation in all weather conditions.
Integrated Omni Antennas
Unlike the AP-567 directional-antenna model, the AP-565 uses built-in omnidirectional antennas. This makes it suitable for applications requiring broad-area outdoor coverage around the access point.
Integrated IoT Connectivity
The AP-565 supports integrated Bluetooth 5 and IEEE 802.15.4/Zigbee connectivity, allowing the access point to support compatible IoT applications alongside conventional Wi-Fi networking.
Applications
- Outdoor enterprise Wi-Fi networks
- Warehouse and logistics facilities
- Campuses and educational institutions
- Hotels and hospitality outdoor areas
- Industrial and manufacturing environments
- Outdoor retail and commercial spaces
- Public venues and outdoor gathering areas
- Transportation and infrastructure sites
- Outdoor IoT deployments
Compatibility
The Aruba AP-565 is part of the HPE Aruba Networking 560 Series and supports Aruba wireless operating systems and Instant deployments. It can be managed through on-premises or cloud-based Aruba management platforms. The exact regulatory SKU and supported frequency bands should be confirmed for the deployment country.
Aruba AP-565 Price in Bangladesh
The Aruba AP-565 price in Bangladesh may vary depending on regional SKU, warranty, mounting accessories and availability. For the latest Bangladesh price and purchasing information, contact Datacom Technologies (BD).
Contact: sales@datacom.com.bd
Why Choose Aruba AP-565?
- Rugged Wi-Fi 6 access point designed specifically for outdoor deployment
- Dual 2x2 MIMO radios for simultaneous 2.4 GHz and 5 GHz connectivity
- Up to 1.49 Gbps peak aggregate wireless data rate
- Integrated omnidirectional antennas for broad outdoor coverage
- IP66/IP67 protection for demanding outdoor environments
- Wide -40°C to +55°C operating temperature range
- Integrated Bluetooth and Zigbee/802.15.4 IoT capabilities
- PoE support for simplified outdoor installation
- Suitable for outdoor, warehouse and industrial wireless deployments
