Aruba AP-735 Wi-Fi 7 Indoor Access Point – Tri-Radio 2x2 with Internal Antennas
The HPE Aruba Networking AP-735 is a next-generation Wi-Fi 7 indoor campus access point designed for enterprise, education, healthcare, retail, and industrial IoT environments. It combines three dedicated 2x2 MIMO radios across the 2.4GHz, 5GHz, and 6GHz bands to deliver high-capacity wireless connectivity with up to 9.3 Gbps maximum aggregate tri-band data rate.
Featuring integrated internal antennas, patented Ultra Tri-Band (UTB) filtering, dual 5Gbps Smart Rate Ethernet ports, and advanced IoT and location capabilities, the Aruba AP-735 provides a scalable wireless platform for high-performance enterprise networks.
Aruba AP-735 Wi-Fi 7 Key Features
- Wi-Fi 7 based on IEEE 802.11be technology with simultaneous 2.4GHz, 5GHz, and 6GHz operation.
- Three dedicated 2x2 MIMO radios for comprehensive tri-band wireless coverage.
- Up to 9.3 Gbps maximum aggregate tri-band wireless data rate.
- Supports up to 14.4 Gbps maximum aggregate data rate using optional dual 5GHz and 6GHz radio modes.
- Integrated internal antennas for streamlined indoor campus installation.
- Dual 5Gbps Smart Rate Ethernet ports provide redundant connectivity and power options.
- Two integrated Bluetooth 5.4 and IEEE 802.15.4 radios support enterprise IoT and Zigbee applications.
- Built-in GNSS receiver and barometric pressure sensor support location-aware wireless deployments.
- Patented Ultra Tri-Band (UTB) filtering improves utilization of the upper 5GHz and lower 6GHz spectrum.
- Supports 320MHz channels on the 6GHz radio for high-throughput Wi-Fi 7 client connectivity.
Aruba AP-735 Technical Specifications
| Specification |
Details |
| Brand |
HPE Aruba Networking |
| Model |
AP-735 |
| Product Type |
Indoor Campus Access Point |
| Wireless Standard |
IEEE 802.11be (Wi-Fi 7) |
| Radio Configuration |
Tri-Radio 2x2 MIMO |
| Frequency Bands |
2.4GHz, 5GHz, and 6GHz |
| 2.4GHz Radio |
2x2 MIMO, up to 688 Mbps |
| 5GHz Radio |
2x2 MIMO, up to 2.9 Gbps |
| 6GHz Radio |
2x2 MIMO, up to 5.8 Gbps |
| Maximum Aggregate Data Rate |
Up to 9.3 Gbps tri-band aggregate |
| Optional Radio Mode |
Dual 5GHz and 6GHz operation, up to 14.4 Gbps aggregate |
| Antenna Type |
Internal antennas |
| Ethernet Ports |
2 x Smart Rate RJ-45 Ethernet ports |
| Ethernet Speed |
100 Mbps, 1 Gbps, 2.5 Gbps, and 5 Gbps |
| IoT Connectivity |
2 x Bluetooth 5.4 and IEEE 802.15.4 radios with Zigbee support |
| USB |
2 x USB 2.0 Type-A host interfaces |
| Location Services |
Built-in GNSS receiver and barometric pressure sensor |
| Wireless Security |
WPA2, WPA3 Enterprise, WPA3 Personal, Enhanced Open (OWE) |
| Channel Width |
Up to 320MHz on supported 6GHz Wi-Fi 7 operation |
| Management |
HPE Aruba Networking Central and supported Aruba networking management platforms |
| Deployment |
Indoor enterprise and campus environments |
| Warranty |
Limited lifetime warranty |
Aruba AP-735 Wi-Fi 7 Applications
- Enterprise office wireless networks
- Corporate campus deployments
- Universities and educational institutions
- Healthcare facilities
- Retail and commercial environments
- High-density indoor wireless networks
- Industrial IoT deployments
- Smart building and location-aware applications
- 6GHz Wi-Fi 7 network deployments
Aruba AP-735 Compatibility
The AP-735 belongs to the HPE Aruba Networking 730 Series Campus Access Points and is designed for enterprise Aruba wireless network environments. It can be managed using HPE Aruba Networking Central and supported Aruba networking management architectures.
The AP-735 uses integrated internal antennas, making it suitable for clean and streamlined indoor installations where an external antenna design is not required.
Aruba AP-735 Indoor Deployment
The Aruba AP-735 is specifically designed as an indoor campus access point. Its tri-radio architecture provides concurrent 2.4GHz, 5GHz, and 6GHz wireless coverage, while Wi-Fi 7 capabilities enable wider channels and higher throughput for compatible client devices.
For enterprise deployments, the dual Smart Rate Ethernet ports can provide high-speed wired connectivity and support redundancy for improved network availability.
Aruba AP-735 Price in Bangladesh
The Aruba AP-735 price in Bangladesh depends on the regional SKU, licensing requirements, deployment accessories, warranty configuration, and current distributor pricing. Contact Datacom Technologies (BD) for the latest Aruba AP-735 price and availability in Bangladesh.
Email: sales@datacom.com.bd
Why Choose Aruba AP-735?
- Next-generation Wi-Fi 7 connectivity with 6GHz support.
- Three dedicated 2x2 MIMO radios for simultaneous tri-band operation.
- Up to 9.3 Gbps maximum aggregate tri-band data rate.
- Optional dual 5GHz and 6GHz radio modes can deliver up to 14.4 Gbps aggregate data rate.
- Internal antenna design provides a clean and professional indoor installation.
- Dual 5Gbps Smart Rate Ethernet ports support high-speed connectivity and redundancy.
- Integrated Bluetooth 5.4 and Zigbee-capable 802.15.4 radios support enterprise IoT.
- Built-in GNSS and barometric sensing support advanced location-aware applications.
- Enterprise-grade wireless security and centralized network management.
For Aruba AP-735 Wi-Fi 7 Indoor Access Point price in Bangladesh, product consultation, licensing guidance, and enterprise wireless deployment support, contact Datacom Technologies (BD) at sales@datacom.com.bd.
