Cisco UCS-M2-HWRAID Boot RAID Controller for UCS Servers – Optimized Boot Storage Solution
The Cisco UCS-M2-HWRAID Boot RAID Controller is a specialized storage controller designed to provide reliable and efficient boot storage for Cisco UCS servers. Built for dual M.2 SATA SSD configurations, this controller enables secure, redundant boot environments—ensuring system availability even in case of drive failure.
Unlike traditional RAID controllers used for bulk storage, the UCS-M2-HWRAID is optimized specifically for operating system boot functionality, offering a compact, high-performance, and cost-effective solution for enterprise servers in Bangladesh.
Full Specifications of Cisco UCS-M2-HWRAID
- Product Type: Boot-Optimized M.2 RAID Controller
- Model: UCS-M2-HWRAID
- Controller Chipset: Marvell 88SE92xx PCIe to SATA Controller
- Interface: PCIe to SATA 6Gb/s
- Drive Support:
- Supports 2× M.2 SATA SSDs
- RAID Levels Supported:
- RAID 1 (Mirror)
- JBOD (default mode)
- Data Transfer Speed: Up to 6Gb/s SATA
- Form Factor: Internal M.2 RAID module
- Boot Mode Support: UEFI only
- Max Logical Drives: 1 (full disk capacity used for single LUN)
- Key Features:
- Boot-optimized storage
- Hardware RAID support
- Redundant OS storage (RAID 1)
- Compact design for internal mounting
- Low power consumption
Best Applications for Cisco UCS-M2-HWRAID in Bangladesh
This controller is ideal for organizations that require secure and stable boot environments:
- Enterprise Servers: Reliable OS boot redundancy
- Data Centers: Dedicated boot storage separate from data drives
- Virtualization Hosts: Secure hypervisor installation (VMware, Hyper-V)
- Banking & Financial Systems: Ensures uninterrupted system boot
- Corporate IT Infrastructure: Stable OS environment for mission-critical servers
- Cloud Deployments: Efficient boot disk management
How to Install Cisco UCS-M2-HWRAID Controller
Follow these steps for proper installation:
- Power Off the Server: Disconnect all power sources
- Open Server Chassis: Remove the server cover
- Install M.2 SSDs:
- Insert two identical M.2 SATA SSDs into the module
- Mount the Controller:
- Install the UCS-M2-HWRAID module into the dedicated slot
- Secure the Module: Ensure proper seating and locking
- Close Chassis & Power On
- Configure RAID:
- Access Cisco UCS Manager or CIMC
- Configure RAID 1 for redundancy
⚠️ Important: Use identical SSDs for RAID configuration to avoid compatibility issues.
Compatibility Devices
The Cisco UCS-M2-HWRAID is compatible with:
- Cisco UCS C220 M5 / M6 Rack Servers
- Cisco UCS C240 M5 / M6 Rack Servers
- Cisco UCS B200 M5 Blade Servers
- Cisco UCS C480 M5 Servers
- Supported Operating Systems:
- VMware ESXi
- Windows Server 2016 / 2019
- Linux (RHEL, CentOS)
Where to Buy Cisco UCS-M2-HWRAID in Bangladesh
Get the Cisco UCS-M2-HWRAID Boot RAID Controller from authorized Datacom Technologies (BD)—100% genuine with full warranty and support.
Buy Cisco UCS-M2-HWRAID at Best Price in Bangladesh from Datacom
You can get the original Cisco UCS-M2-HWRAID Boot RAID Controller from Datacom Technologies BD. We have a large collection of the latest Cisco server RAID controllers and accessories available for purchase. Order online or visit our Datacom shop at Elephant Road, Dhaka to get the best price.
The Cisco UCS-M2-HWRAID Boot RAID Controller is available with a 1-year warranty.
