Dell K4D64 PCIe 2x M.2 Boss-S1 RAID Controller Card for PowerEdge 14G Specification |
Details |
|---|
| Model / Part Number | K4D64 |
| Product Name | Dell BOSS-S1 PCIe RAID Controller Card |
| Category | Boot Optimized Storage Solution (BOSS) Adapter |
| Interface (Host) | PCIe Gen 2.0 ×8 physical (electrically ×2) |
| Supported Drive Types | Up to 2 × M.2 SATA SSDs (6 Gb/s) |
| M.2 Form Factor Supported | 2280 SATA SSDs |
| RAID Support | RAID 1 (hardware mirroring) |
| Non-RAID Support | Yes — supports up to two standalone drives |
| Maximum Virtual Disks | 1 |
| Default Stripe Size | 64 KB |
| Write Cache Policy | Write-through (no non-volatile cache) |
| Battery / Backup Cache | No |
| Status LEDs on Card | No |
| Form Factor | PCIe add-in card (low-profile/full-height compatible) |
| Typical Use Case | OS boot drive mirroring for servers |
| Compatible With | Dell PowerEdge 14G series servers (PowerEdge R240, R340, R440, R540, R640, R740, R740xd, R940, T140, T340, T440, T640, etc.) |
| Drive Support Notes | SATA M.2 only (NVMe not supported) |
Description For Dell K4D64 PCIe 2x M.2 Boss-S1 RAID Controller Card for PowerEdge 14G
The Dell K4D64 BOSS-S1 PCIe RAID Controller Card is a specialized boot-optimized storage adapter designed to deliver simple, reliable operating system storage for Dell PowerEdge 14th-generation servers. It provides two M.2 SATA SSD slots, allowing the installation of SATA-based M.2 drives that host the server’s boot volume. Through built-in hardware RAID 1 support, the K4D64 enables mirrored configurations, meaning the OS remains available even if one SSD fails — a key feature for mission-critical and always-on environments.
This controller card connects via a PCIe Gen 2.0 ×8 interface (with two electrical PCIe lanes), and supports both RAID and non-RAID modes. It creates a single virtual disk for the system boot drive when RAID is used, with a fixed 64 KB stripe size and standard write-through caching for data integrity. Unlike full-featured RAID adapters, the BOSS-S1 does not include a battery backup or non-volatile cache.
Optimized for system boot and OS storage, the K4D64 frees up traditional drive bays for data storage by placing the OS on dedicated M.2 SSDs — a valuable advantage in dense server configurations. It’s widely deployed across PowerEdge models such as R240, R440, R540, R640, R740, R740xd, T140, T340, T440, and T640 series servers.
Dell K4D64 PCIe 2x M.2 BOSS-S1 RAID Controller Card for PowerEdge 14G | Datacom Technologies BD
Enhance Your PowerEdge 14G Server with Genuine Dell Storage Optimization
The Dell K4D64 PCIe 2x M.2 BOSS-S1 RAID Controller Card offers a powerful, reliable boot and storage solution for Dell PowerEdge 14th Generation servers. Engineered for performance, resilience, and enterprise workloads, this controller card delivers optimized boot operations and high availability for mission-critical environments.
What Is Dell K4D64 BOSS-S1 Controller Card?
The Dell K4D64 BOSS-S1 is a dedicated RAID controller card that supports two M.2 SATA SSDs configured in a RAID array (commonly RAID 1). By offloading boot functions to the M.2 SSDs, this controller helps improve DB performance and frees up front drive bays for additional data storage.
Key Benefits of Dell K4D64 for PowerEdge 14G Servers
???? Improved Boot Performance
The controller offloads the operating system to dedicated M.2 SSDs, resulting in:
- Faster system boot times
- Reduced load on primary storage
- Enhanced server responsiveness
???? Enterprise-Grade RAID Protection
With RAID 1 support, the K4D64 controller delivers:
- Data redundancy for the OS
- Protection against drive failure
- Higher availability for critical systems
???? Designed for Dell PowerEdge 14G Compatibility
This controller is engineered to work effortlessly with Dell PowerEdge 14th Gen servers, such as:
- PowerEdge R740
- PowerEdge R740xd
- PowerEdge R640
- PowerEdge R440
Ensuring plug-and-play installation without firmware conflicts.
???? Efficient Use of Storage Resources
By using M.2 SSDs for OS boot functions, organizations can:
- Free up hot-plug drive bays for bulk storage
- Maximize I/O performance for data workloads
- Improve server cooling and space utilization
Ideal Use Cases
The Dell K4D64 PCIe 2x M.2 BOSS-S1 RAID Controller Card is perfect for:
- ✨ Virtualized environments (VMware, Hyper-V, etc.)
- ✨ Database and transaction servers
- ✨ Cloud infrastructure workloads
- ✨ Enterprise applications requiring high uptime
When you purchase the Dell K4D64 BOSS-S1 RAID Controller Card from Datacom Technologies BD, you benefit from:
- ✅ 100% genuine Dell hardware
- ✅ Best price in Bangladesh (BD)
- ✅ Full pre-sales & after-sales support
- ✅ Expert technical guidance for installation & compatibility
- ✅ Fast nationwide delivery
We are a trusted IT hardware supplier committed to helping your business scale with reliable server infrastructure.
Buy Dell Dell K4D64 PCIe 2x M.2 Boss-S1 RAID Controller Card for PowerEdge 14G at the Best Price from Datacom Technologies BD.
In Bangladesh, you can get Dell K4D64 PCIe 2x M.2 Boss-S1 RAID Controller Card for PowerEdge 14G From Datacom Technologies BD. We have a large collection of latest Dell Boss Card to purchase for your Server. Order Online Or Visit our Office to get yours at lowest price. The Dell K4D64 PCIe 2x M.2 Boss-S1 RAID Controller Card comes with 1 Year warranty.
