Finisar FTCC8612E1PCM 200Gbps QSFP56 Optical Transceiver Module

The Finisar FTCC8612E1PCM is a 200Gbps QSFP56 optical transceiver designed for short-reach 200G Ethernet connectivity over parallel multimode fiber. It supports up to 100 meters on OM4 MMF and is intended for high-density data center and high-performance networking environments.

The module uses four 50Gbps PAM4 optical lanes and an MPO-12 optical interface. Its QSFP56 form factor provides a compact, hot-pluggable solution for compatible 200Gbps networking equipment. :contentReference[oaicite:0]{index=0}

Finisar FTCC8612E1PCM 200GBASE-SR4 Connectivity

The FTCC8612E1PCM is designed for 200GBASE-SR4 Ethernet applications. It supports an aggregate bit rate of up to 212.5Gbps using four 50Gbps PAM4 optical channels, providing high-bandwidth connectivity for modern data center infrastructure. :contentReference[oaicite:1]{index=1}

The parallel optical architecture is designed for short-distance connections between compatible high-speed switches, servers, and other networking equipment.

850nm Multimode Fiber Transmission

The transceiver operates at 850nm and is designed for parallel multimode fiber. It supports up to 70m on OM3 MMF and up to 100m on OM4 MMF. The 100m OM4 reach is specified with FEC. :contentReference[oaicite:2]{index=2}

Four-Channel PAM4 Architecture

The module uses 4 × 50Gbps PAM4 optical channels to provide the 200Gbps-class connection. This architecture enables high aggregate bandwidth while maintaining the compact QSFP56 form factor required for high-density network deployments. :contentReference[oaicite:3]{index=3}

QSFP56 and MPO-12 Interface

The QSFP56 form factor provides a hot-pluggable interface for compatible 200Gbps network equipment. The optical connection uses an MPO-12 connector for parallel multimode fiber transmission. :contentReference[oaicite:4]{index=4}

Digital Diagnostic Monitoring

The FTCC8612E1PCM provides digital diagnostic functions through its I2C management interface, as specified by CMIS 4.0. Compatible host equipment can use the management interface to monitor supported module operating parameters. :contentReference[oaicite:5]{index=5}

Technical Specifications

Applications

• 200GBASE-SR4 Ethernet networks
• Data center interconnects
• High-density switch-to-switch links
• High-performance computing networks
• AI and accelerated computing infrastructure
• Short-reach multimode fiber connectivity

Compatibility

The Finisar FTCC8612E1PCM is designed for compatible networking equipment supporting 200GBASE-SR4 QSFP56 optical transceivers. The module is documented as compliant with the QSFP MSA and applicable IEEE 802.3 specifications, with digital diagnostics available through the CMIS 4.0 management interface. :contentReference[oaicite:6]{index=6}

Before installation, verify the host device's supported QSFP56 transceiver list, FEC requirements, MPO fiber configuration, and OM3 or OM4 multimode fiber specifications.

Buy Finisar FTCC8612E1PCM in Bangladesh

Datacom Technologies (BD) supplies Finisar optical transceivers, enterprise networking equipment, fiber connectivity products, and data center hardware in Bangladesh. The Finisar FTCC8612E1PCM is suitable for compatible 200Gbps networking environments requiring short-reach multimode fiber connectivity.

For corporate, data center, ISP, telecom, and project requirements, customers can contact Datacom Technologies (BD) for product selection assistance, technical consultation, and professional networking equipment supply.
