Aruba AP-505H Wi-Fi 6 Indoor Hospitality Access Point – Dual 2x2 MIMO, 1.49 Gbps
The HPE Aruba Networking AP-505H is a high-performance Wi-Fi 6 indoor hospitality and remote-office access point designed for hotels, guest rooms, branch offices, and other low-to-medium-density environments. It provides concurrent 2.4 GHz and 5 GHz 802.11ax connectivity with dual 2x2 MIMO radios.
The AP-505H combines reliable Wi-Fi 6 connectivity with integrated Bluetooth Low Energy and Zigbee/802.15.4 capabilities, making it suitable for IoT-enabled hospitality and enterprise deployments. It also provides a 2.5Gbps Smart Rate uplink, four Gigabit Ethernet downlink ports, USB 2.0 connectivity, and PoE-powered downstream devices.
Aruba AP-505H Key Features
- Wi-Fi 6 (802.11ax) dual-radio 2x2 MIMO architecture
- Up to 1.49 Gbps combined peak wireless data rate
- 2.5Gbps Smart Rate Ethernet uplink
- Four 10/100/1000BASE-T local Ethernet ports
- Two local ports support PoE-PSE output for connected devices
- Integrated Bluetooth Low Energy 5.0 and Zigbee/802.15.4 radio
- USB 2.0 Type-A host interface with up to 5W power sourcing
- WPA3, WPA2 and Enhanced Open security support
- OFDMA, MU-MIMO, Target Wake Time and ClientMatch technologies
- Supports controller-based AOS-8/AOS-10 and Instant deployments
Technical Specifications
| Specification | Details |
|---|
| Brand | HPE Aruba Networking |
| Model | AP-505H |
| Product Type | Indoor Hospitality / Remote Office Access Point |
| Wireless Standard | IEEE 802.11ax (Wi-Fi 6) |
| Wireless Radios | Dual radio, 2x2 MIMO |
| 2.4 GHz Radio | 2x2 MIMO, up to 287 Mbps wireless data rate using HE20 |
| 5 GHz Radio | 2x2 MIMO, up to 1.2 Gbps wireless data rate using HE80 |
| Combined Peak Rate | Up to 1.49 Gbps |
| Uplink Ethernet | 1 x 10/100/1000/2500BASE-T RJ-45 Smart Rate port |
| Downlink Ethernet | 4 x 10/100/1000BASE-T RJ-45 ports |
| PoE-PSE | E1 and E2 support PoE output for downstream devices |
| IoT Connectivity | Integrated Bluetooth Low Energy 5.0 and Zigbee/802.15.4 |
| USB | USB 2.0 Type-A host interface, up to 5W power sourcing |
| Antennas | Integrated semi-directional 2x2 MIMO antennas |
| Security | WPA2, WPA3-Enterprise, WPA3-Personal (SAE), Enhanced Open (OWE) |
| Management | Controller-based AOS and Instant operating modes |
| Power | 802.3af/at/bt PoE or DC power |
| Dimensions | 150 x 86 x 47 mm |
| Weight | Approximately 360 g |
| Operating Temperature | 0°C to 40°C |
| Warranty | Limited lifetime warranty |
Designed for Hospitality and Remote Office Networks
The Aruba AP-505H is designed for environments where users need dependable wireless connectivity alongside wired Ethernet access. Its compact hospitality-oriented design makes it suitable for guest rooms, serviced apartments, branch offices, remote workspaces, and similar indoor deployments.
Wi-Fi 6 Performance
Dual 2x2 MIMO radios provide simultaneous 2.4 GHz and 5 GHz Wi-Fi 6 connectivity. OFDMA and MU-MIMO improve wireless efficiency when serving multiple compatible clients, while ClientMatch helps optimize client association and roaming.
Integrated Wired Connectivity
The AP-505H provides one 2.5Gbps Smart Rate uplink and four Gigabit Ethernet downlink ports. Two of the local Ethernet ports can provide PoE-PSE output, allowing compatible downstream devices to receive power directly from the access point.
IoT and USB Connectivity
Built-in Bluetooth Low Energy and Zigbee/802.15.4 radios enable the AP-505H to operate as an IoT gateway for compatible devices. The USB 2.0 Type-A host interface can support cellular modems, IoT accessories, or other compatible peripherals and can source up to 5W.
Applications
- Hotels and hospitality properties
- Guest rooms and serviced apartments
- Branch and remote offices
- Small business wireless networks
- Retail and customer-facing environments
- IoT-enabled hospitality deployments
- Remote workforce and distributed office locations
Compatibility
The Aruba AP-505H is designed for HPE Aruba Networking environments and supports controller-based and Instant deployment architectures. Deployment should be planned according to the required Aruba software version, regional regulatory requirements, mounting accessories, and PoE budget.
Aruba AP-505H Price in Bangladesh
The Aruba AP-505H price in Bangladesh can vary depending on configuration, regional variant, warranty, accessories, and availability. For the latest Bangladesh price and purchasing information, contact Datacom Technologies (BD).
Contact: sales@datacom.com.bd
Why Choose Aruba AP-505H?
- Enterprise-grade Wi-Fi 6 connectivity in a compact hospitality-focused form factor
- Dual 2x2 MIMO radios with up to 1.49 Gbps combined peak wireless rate
- 2.5Gbps Smart Rate uplink for high-speed wired networking
- Four additional Gigabit Ethernet ports for connected devices
- Integrated Bluetooth and Zigbee/802.15.4 IoT connectivity
- USB connectivity for compatible cellular and IoT accessories
- Suitable for hotels, branch offices, remote offices, and other indoor deployments
