Finisar FTLX1871D3BCL 10Gbps 80KM SFP+ Optical Transceiver Module

The Finisar FTLX1871D3BCL is a long-distance 10Gbps SFP+ optical transceiver designed for high-speed network connectivity over G.652 single-mode fiber. It supports multi-rate links from 8.5Gbps through 11.3Gbps and provides a maximum transmission distance of up to 80km.

The module uses a cooled 1550nm EML laser and a limiting electrical receiver interface. It features a hot-pluggable SFP+ form factor and duplex LC optical connector for compatible long-reach network equipment. ([coherent.com](https://www.coherent.com/resources/datasheet/networking/optical-transceivers/sfp/ftlx1871d3bcl-transceiver-ds.pdf?utm_source=chatgpt.com))

Finisar FTLX1871D3BCL 10GBASE-ZR Connectivity

The FTLX1871D3BCL is designed for 10G Ethernet ZR and 10G Fibre Channel applications. Its multi-rate operation supports 8.5Gbps and 9.95Gbps to 11.3Gbps, allowing the transceiver to be used across several compatible high-speed optical applications.

The module is particularly suited to long-distance backbone, telecommunications, enterprise, and data center links where an 80km optical reach is required.

80KM Single-Mode Fiber Transmission

The transceiver supports links of up to 80km over G.652 single-mode fiber. Its long-reach optical design is intended for extended-distance network connections where standard 10km or 40km SFP+ modules do not provide sufficient reach.

1550nm EML Laser

The module uses a cooled 1550nm EML laser for optical transmission. The laser architecture is designed for long-distance single-mode fiber applications and provides the optical characteristics required for extended-reach 10Gbps links. ([coherent.com](https://www.coherent.com/resources/datasheet/networking/optical-transceivers/sfp/ftlx1871d3bcl-transceiver-ds.pdf?utm_source=chatgpt.com))

SFP+ and Duplex LC Interface

The compact SFP+ form factor provides a hot-pluggable interface for compatible networking equipment. A duplex LC connector provides separate optical transmit and receive paths over the single-mode fiber link.

Digital Diagnostic Monitoring

The FTLX1871D3BCL provides built-in digital diagnostic functions through a 2-wire serial interface in accordance with SFF-8472. This allows compatible host equipment to monitor supported optical operating parameters. ([coherent.com](https://www.coherent.com/resources/datasheet/networking/optical-transceivers/sfp/ftlx1871d3bcl-transceiver-ds.pdf?utm_source=chatgpt.com))

Technical Specifications

Applications

• 10G Ethernet ZR networks
• 10G Fibre Channel
• Long-distance network backbone links
• Telecommunications infrastructure
• Enterprise network connectivity
• Data center interconnects
• 80km single-mode fiber links

Compatibility

The Finisar FTLX1871D3BCL is designed for compatible networking equipment supporting multi-rate SFP+ optical transceivers. Finisar documentation specifies support for 10G Ethernet ZR and 10G Fibre Channel, with compliance to SFF-8431, SFF-8432, and SFF-8472. ([coherent.com](https://www.coherent.com/resources/datasheet/networking/optical-transceivers/sfp/ftlx1871d3bcl-transceiver-ds.pdf?utm_source=chatgpt.com))

Before installation, verify the host device's supported SFP+ transceiver list, operating data rate, optical interface, firmware requirements, and single-mode fiber specifications. For an 80km deployment, the complete optical link budget should also be evaluated.

Buy Finisar FTLX1871D3BCL in Bangladesh

Datacom Technologies (BD) supplies Finisar optical transceivers, enterprise networking equipment, fiber connectivity products, and data center hardware in Bangladesh. The Finisar FTLX1871D3BCL is suitable for compatible 10Gbps networking environments requiring extended-reach single-mode fiber connectivity.

For corporate, data center, ISP, telecom, and project requirements, customers can contact Datacom Technologies (BD) for product selection assistance, technical consultation, and professional networking equipment supply.
